INTRODUCTION • SMARTSENSOR ADVANCE USER GUIDE
6
structions for both automatic and manual sensor configurations. Any questions about the
information in this guide should be directed to Wavetronix or your distributor.
Caution
Do not attempt to service or repair this unit. This unit does not contain any compo-
nents and/or parts serviceable in the field. Any attempt to open this unit, except
as expressly written and directed by Wavetronix, will void the customer warranty.
Wavetronix is not liable for any bodily harm or damage caused if service is attempted
or if the back cover of the SmartSensor unit is opened. Refer all service questions to
Wavetronix or an authorized distributor.
SmartSensor Advance Package
A typical SmartSensor Advance package will commonly include:
˽ 10.525 GHz SmartSensor Advance radar traffic sensor
˽ SmartSensor mounting kit
˽ SmartSensor 6-conductor cable
˽ SmartSensor Advance preassembled backplate
˽ SmartSensor Manager Advance (SSMA) software
˽ SmartSensor Advance User Guide
˽ SmartSensor Advance Quick-reference Guides
Check the packing slip for actual contents. If any of these items are missing, note the serial
number located on the back of the sensor and contact your distributor.
Selecting a Detection Method
Consult the Wavetronix guidelines for integration of SmartSensor Advance into your traf-
fic control system. For dilemma zone protection applications, integration guidelines can be
found on the Wavetronix website and Wavetronix application notes. Contact your dealer or
a Wavetronix Technical Services representative if the application-specific documentation
does not fully answer your system integration and configuration questions.
Some examples of traffic control applications include:
˽ Dilemma zone protection using green extension
˽ Truck signal priority using green extension
˽ Dilemma zone protection using green extension with an Advanced Warning Sign
(AWS)
Dilemma zone protection using red extension
˽
