Appendix

In this chapter
13
Appendix A – Cable Connector Definitions
The connector end of the SmartSensor 6-conductor cable mates to the 8-pin connector on
the SmartSensor Advance (see Figure A.1).
The SmartSensor 6-conductor cable has seven wires. Table A.1 details the pinout of the
˽ A - Cable Connector Definitions
˽ B - Cable Lengths
˽ C - Direct Serial Connections
˽ D - Target Roll Angles for Alignment
F
Figure A.1 – SmartSensor Advance Connector
G
A
H
B
E C
D
