Installing the SmartSensor Advance
In this chapter
1
Installing the SmartSensor Advance is quick and easy. Once installed, SmartSensor Ad-
vance requires little or no on-site maintenance. This chapter describes the installation pro-
cess, including how to attach the sensor to the pole and how to correctly align the sensor.
Warning
Caution should be used when installing any sensor on or around active roadways.
Serious injury can result when installation is performed using methods that are not
in accordance with authorized local safety policy and procedures. Always maintain an
appropriate awareness of the traffic conditions and safety procedures as they relate
to specific locations and installations.
Selecting the Mounting Height
Select a mounting location within the recommended range of offsets from the center of
˽ Selecting the Mounting Height
˽ Attaching the Mount Bracket to the Pole
˽ Attaching the Sensor to the Mount Bracket
˽ Aligning the Sensor to the Roadway
˽ Applying Silicon Dielectric Compound
˽ Connecting the SmartSensor Cable to the Sensor
