Baud Rate
Channel Input Map
Autobaud
Reset to Default
Description
Location
Device ID
Fail-safe Settings
To use this
configuration option:
Table 12.1 – Click 104 Configuration Options
If you have used the rotary switch to set the channel input mapping (which is the only
thing you can do with the rotary switch), that mapping cannot be set or changed with the
front panel menu or Click Supervisor. If the rotary switch is set to 0, you can set channel
input mapping using Click Supervisor or the front panel menu.
Note
If any setting has been set using both the front panel menu and Click Supervisor,
whichever configuration was set most recently will be the one that counts.
See the Click 100-400 Series User Guide for more information on these contact closure
devices.
CHAPTER 12 • PROGRAMMING CONTACT CLOSURES
Rotary Switch Front Panel Menu
No Yes
Yes Yes
No Yes
No Yes
No No
No No
No No
No No
Hardware mode Software mode
Click Supervisor
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Software mode
125
