CHAPTER 10 • TEMPLATES
106
Creating a Channel Template
A template can be created from any of the SmartSensor Advance's eight detection chan-
nels. Follow the steps below to specify the channel to be used as a template:
1
Select the desired channel from the drop-down list.
2
Specify the file to be created by clicking on the file icon (see Figure 10.2).
3
Click the Create Template button to create the template.
Importing a Channel Template
The SSMA software contains pre-defined channel templates that can be modified to meet
your needs. An existing channel template can be loaded into any of the SmartSensor Ad-
vance's eight detection channels. Follow the steps below to specify the channel to receive
the template:
1
Select the desired channel from the drop-down list.
2
Specify the file to be imported and click OK (see Figure 10.3).
3
Click the Import Template button to load the template. A pop-up screen will appear
listing the CAZ elements being modified. A pop-up message will notify you if the
template file contains an error.
Figure 10.2 – Create Template File Screen
