Installation - Step 1/2
Install the power control unit Ⓒ according to the following instructions.
PCU6.3-F
Fixed 3-phase connection.
See pages 6-7.
PCU6.3-P
Perilex-connectors.
See pages 8-9.
PCU6.1-F
Fixed 1-phase connection.
See pages 10-11.
4
Mount the Power Control Unit Ⓒ
PCU6.1-P
1-phase, 3-pin plug OUT.
See pages 12-13.
PCU6.1-S
Schuko-connectors.
See pages 14-15.
5
