3. Installation troubleshooting

Problem Remedy
Problems with checking •
the working order: the
cooker power does not •
shut down
•
Cooker cannot be turned See user manual chapters 3.2 or 3.3. If the problem persists,
on after pressing the OK the appliace might be faulty. Press the OK button ❸ to find
button ❸. out the problem type by the indicator light ❹:
Indicator light ❹ blinks in blue:
•
•
•
Indicator light ❹ blinks in yellow:
•
•
•
Faulty installation
Sensor unit Ⓐ will automatically recognize its'
position of the sensor
installation position during the first time the cooker
unit Ⓐ.
is used for cooking. After the auto-recognition is
completed, the stove guard will prevent the use of
cooker and oven if the sensor unit Ⓐ is removed from
its' original installation position. To enable use of the
cooker, place the sensor unit Ⓐ back to the mounting
bracket Ⓑ. If the problem persists, the auto-recognition
might not have been successful. Ensure the correct
position of the sensor unit Ⓐ (see installation step
2/2) and manually reconnect the wireless connection
according the installation manual chapter 4.2. The fault
should be then reseted automatically in two minutes.
The wireless connection Go into the Manual adjustment mode and set up the
is not working. wireless connection manually, see chapter 4.
The sensor unit Ⓐ is not Ensure that the batteries are not empty. Check the correct
responding to any button position of the batteries marked on the bottom of the
and none of the indicator battery case.
lights are lit.
The appliance turns
Make sure that the power control unit Ⓒ is connected
off the power from correctly – in other words, the cooker is connected to the
the cooker, but the OUT cable.
power comes back on
immediately.
18
Retry with the same cooker plate and ensure that the
plate is set on highest power level.
With an induction cooker use a suitable dish so that the
cooker is consuming power.
Check all wiring of the Power control unit Ⓒ.
Blinks once: Problem with wireless connection.
Blinks twice: Problem with power control unit Ⓒ.
Blinks three times: Power control unit Ⓒ over-heating.
Blinks once: Probem with sensors ❻.
Blinks twice: Problem with sensor unit Ⓐ
Blinks three times: Faulty installation position of the sen-
sor unit Ⓐ

4. Manual adjustment mode

To enable the fast installation, the default settings of Safera Airis are suitable for the
most typical installations. In case you need to install the sensor unit outside the de-
fault installation dimensions or replace the cooker, sensor unit or power control unit
in the original installation, you need to enter the manual adjustment mode.
Press the adjustment button ❷ for 5 seconds and you will enter the manual adjust-
ment mode 1. You may move to the next mode by pressing OK-button ❸:
Mode Setting
Mode 1 Alarm limit settings
Mode 2 Manual setup of the wireless
connection
Mode 3 Manual calibration of the
cooker type
Mode 4 Testing and adjusting AUX-con-
nection
4.1 Mode 1: Alarm limit settings
When the indicator light ❹ will lit white, you may adjust the alarm limit:
1. Check the closest recommended alarm limit from the reference table 1 below.
2. Adjust the alarm limit accordingly (the default setting is 6):
• You may raise the alarm limit (+1): press the adjustment button 2.
• You may lower the alarm limit (-1): press the adjustment button 1.
3. After adjusting the the alarm limit, the new alarm limit is indicated as shown in the
table 2 and the stove guard will automatically exit the manual adjustment mode.
To move to the manual adjustment mode 2 without changes in mode 1, press OK but-
ton .
❸
Table 1: Recommended alarm limit reference table based on the location of the cook-
er and the installation height. The range is 1 - 12 (1 = reacts fastest, 12 = reacts slowest).
Recommended Installation height:
alarm limit
Mounting on the wall
3 -
4 -
5 45 - 50 cm
6* 50 - 60 cm
7 -
* default
Indicator light ❹
Lit white
Blinking purple-blue
Blinking yellow-green
Blinking white (normal AUX-mode), or
Blinking red (inversed AUX-mode)
Installation height:
Mounting under the cooker hood
85 - 95 cm
75 - 85 cm
65 - 75 cm
55 - 65 cm
45 - 55 cm
