HDC-301MS Video Capture Card
MODEL:
HDC-301MS-R10
Video/Audio Capture Card with
HDMI Input Channel,1920x1080@30p,
and H.264 Hardware Encoder
User Manual
Page I
Rev. 1.00 – September 4, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDC-301MS-R10 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology HDC-301MS-R10

Summary of Contents for IEI Technology HDC-301MS-R10

  • Page 1 HDC-301MS Video Capture Card MODEL: HDC-301MS-R10 Video/Audio Capture Card with HDMI Input Channel,1920x1080@30p, and H.264 Hardware Encoder User Manual Page I Rev. 1.00 – September 4, 2015...
  • Page 2 HDC-301MS Video Capture Card Revision Date Version Changes September 4, 2015 1.00 Initial release Page II...
  • Page 3 HDC-301MS Video Capture Card Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 HDC-301MS Video Capture Card Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    HDC-301MS Video Capture Card Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 F ........................2 EATURES 1.3 A ......................3 PPLICATIONS 1.4 C ..................... 3 ONNECTOR VERVIEW 1.5 S ......................4 PECIFICATIONS 1.6 D ....................... 6 IMENSIONS 2 HARDWARE INSTALLATION...................
  • Page 6 HDC-301MS Video Capture Card B.1 H IPB P AZARDOUS ATERIAL ISCLOSURE ABLE FOR RODUCTS ERTIFIED AS HS C 2002/95/EC W ........30 OMPLIANT NDER ITHOUT ERCURY Page VI...
  • Page 7 HDC-301MS Video Capture Card List of Figures Figure 1-1: HDC-301MS Video Capture Card ................2 Figure 1-2: HDC-301MS Connector Overview................3 Figure 1-3: HDC-301MS Dimensions (mm) ..................6 Figure 2-1: HDC-301MS Installation....................10 Figure 2-2: HDC-304E HDMI Output Kit Connector Location...........11 Figure 3-1: Device Driver Installation Wizard Welcome Window ..........14 Figure 3-2: Windows Security Window ..................14 Figure 3-3: Driver Installing ......................15 Figure 3-4: Driver Installation Complete ..................15...

  • Page 8: List Of Tables

    HDC-301MS Video Capture Card List of Tables Table 1-1: Specifications .......................6 Table 2-1: Package List Contents ....................9 Table 2-2: HDMI Input Connector Pinouts .................11 Page VIII...

  • Page 9: Introduction

    HDC-301MS Video Capture Card Chapter Introduction Page 1...

  • Page 10: Overview

    HDC-301MS Video Capture Card 1.1 Overview Figure 1-1: HDC-301MS Video Capture Card The low power HDC-301MS video capture card supports 1080p Full HD video via HDMI connection. The HDC-301MS video capture card is equipped with the high-performing encoder component with the HDMI video input channel and either audio input channel. A software development kit (SDK) is shipped with each card and the flexible system architecture simplifies the integration of cameras, video signal processing, storage and video management and or security applications.

  • Page 11: Applications

    HDC-301MS Video Capture Card 1.3 Applications Some possible applications include:  Video game  DVD/Blue-ray player,  Camcorder  Video surveillance  Video analyzer  Video post production 1.4 Connector Overview NOTE: The other connectors, jumpers and interfaces on the board not specified below are for R&D diagnostic purposes and should not be used by the end user.

  • Page 12: Specifications

    HDC-301MS Video Capture Card 1.5 Specifications The HDC-301MS specifications are listed in the table below: HDC-301MS Video Input Channel HDMI Video Input Type Audio Input Channel HDMI Audio Input Type PCIe Mini PC Interface VIDEO PROCESSING H.264/AVC High Profile Level 4.1 (hardware Video Compression compression) Up to 30 Mbps...
  • Page 13 HDC-301MS Video Capture Card HDC-301MS 1920 x 1080 24p/25p/30p 1440 x 900 1360 x 768 1280 x 1024 1280 x 800 1280 x 768 Recording Resolution 1280 x 720 50p/60p 1024 x 768 800 x 600 720 x 576 720 x 480 640 x 480 AUDIO PROCESSING 44.1 k, 48 kHz...

  • Page 14: Dimensions

    HDC-301MS Video Capture Card HDC-301MS SDK provided with demo program OTHERS 51 mm x 30 mm Dimensions (WxH) 0ºC – 60ºC (32ºF – 140ºF), non-condensing Operating Temperature Power Consumption Table 1-1: Specifications 1.6 Dimensions The dimensions for the HDC-301MS are listed below. Figure 1-3: HDC-301MS Dimensions (mm) Page 6...

  • Page 15: Hardware Installation

    HDC-301MS Video Capture Card Chapter Hardware Installation Page 7...

  • Page 16: Unpacking

    HDC-301MS Video Capture Card 2.1 Unpacking 2.1.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the video capture card may result in permanent damage to the capture card and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the video capture card.

  • Page 17: Unpacking Checklist

    HDC-301MS Video Capture Card 2.1.3 Unpacking Checklist NOTE: If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the video capture card from or contact an IEI sales representative directly.

  • Page 18: Hardware Installation

    HDC-301MS Video Capture Card 2.2 Hardware Installation To install the HDC-301MS video capture card into a system and connect the HDMI input cable, please follow the steps below: Step 1: Connect the HDMI input cable to the HDMI input connector on the HDC-301MS.

  • Page 19: Hdmi Input Connector (Jr1)

    HDC-301MS Video Capture Card 2.2.1 HDMI Input Connector (JR1) The HDMI input connector connects to the HDMI input cable that provides an HDMI input port. Pinouts for the connector are shown in Table 2-2. Pin No. Description Pin No. Description HDMI_IN_RX2+ GROUND GROUND...

  • Page 20: Driver Installation (Windows)

    HDC-301MS Video Capture Card Chapter Driver Installation (Windows) Page 12...

  • Page 21: Overview

    HDC-301MS Video Capture Card 3.1 Overview A CD is shipped with the video capture card. The CD contains a driver for the video capture controllers on the card. When the video capture card is installed on the system, the driver must be installed. Failure to install the driver means that that video capture card cannot be detected by the system.

  • Page 22: Figure 3-1: Device Driver Installation Wizard Welcome Window

    HDC-301MS Video Capture Card Figure 3-1: Device Driver Installation Wizard Welcome Window Step 5: The following window appears to confirm the installation. Click Install. Figure 3-2: Windows Security Window Step 6: The driver starts to install and the screen in Figure 3-3 appears. Page 14...

  • Page 23: Figure 3-3: Driver Installing

    HDC-301MS Video Capture Card Figure 3-3: Driver Installing Step 7: When the driver installation is complete, click the Finish button to finish driver installation. Figure 3-4: Driver Installation Complete Step 8: Check the Device Manager in the Windows control panel to ensure the HDC-301MS driver has been properly installed.

  • Page 24: Uninstall Driver

    HDC-301MS Video Capture Card Single Card: Multiple Cards: Figure 3-5: Device Manager NOTE: If the user fails to install the driver by following the above procedure, please install the HDC-301MS driver manually in the Device Manager. To do this, right click HDC-301MS in the Device Manager, and select Update Driver Software.

  • Page 25: Iei Hd Capture Ap (Windows)

    HDC-301MS Video Capture Card Chapter IEI HD Capture AP (Windows) Page 17...

  • Page 26: Software Installation (Windows)

    HDC-301MS Video Capture Card 4.1 Software Installation (Windows) The HDC-301MS comes with a video capture application – IEI HD Capture AP. This section describes how to install the application in Windows environment. 4.1.1 System Requirements The supported OS versions are listed below: ...

  • Page 27: Figure 4-1: Iei Hd Capture Full X86 Setup Wizard Welcome Window

    HDC-301MS Video Capture Card Figure 4-1: IEI HD Capture Full x86 Setup Wizard Welcome Window Step 4: Select a folder for IEI HD Capture AP installation in Figure 4-2. Click Next to continue. Figure 4-2: Select Installation Folder Step 5: The following screen appears.

  • Page 28: Figure 4-3: Confirm Installation

    HDC-301MS Video Capture Card Figure 4-3: Confirm Installation Step 6: The system starts installing the IEI HD Capture AP. Figure 4-4: Installing IEI HD Capture AP Step 7: When the IEI HD Capture AP is successfully installed, the following window appears.

  • Page 29: Using Iei Hd Capture Application

    HDC-301MS Video Capture Card Figure 4-5: Installation Complete 4.2 Using IEI HD Capture Application The IEI HD Capture AP is a video capture tool that allows user to capture video through the HDMI input ports in Windows environment. To use the IEI HD Capture AP to capture video, follow the steps below. If the older version of the IEI HD Capture AP is already installed, please refer to Section 4.3 to uninstall it.

  • Page 30: Figure 4-6: Iei Hd Capture Ap

    HDC-301MS Video Capture Card Figure 4-6: IEI HD Capture AP Step 3: The Encode Setting window appears (Figure 4-7). Make necessary configuration setting by following the guideline below:  Audio Enable: check to enable the audio encoding Sample Rate: select the sample rate of the audio Volume: select the volume amount for encoding ...

  • Page 31: Figure 4-7: Encode Setting

    HDC-301MS Video Capture Card Figure 4-7: Encode Setting Step 4: After finishing the setting configuration, click OK to save the settings. Step 5: To start capture the video, click the Start button on the IEI HD Capture AP user interface. The Save File As window appears. Specify a location to save the encoded video file, and change the file name as necessary.

  • Page 32: Uninstall Iei Hd Capture Ap

    HDC-301MS Video Capture Card Figure 4-8: IEI HD Capture AP – Stop Button 4.3 Uninstall IEI HD Capture AP To uninstall the IEI HD Capture AP, follow the steps below. Select Control Panel  Programs  Programs and Features. Step 1: Step 2: Select IEI HD Capture AP and click the Uninstall button.

  • Page 33: Faq

    HDC-301MS Video Capture Card Chapter Page 25...
  • Page 34 HDC-301MS Video Capture Card Capture card, driver, application and input source are all ready, but the recorded video is not displayed or displayed incorrectly. In this situation, a H.264 video codec must be installed to display the recorded video -- the ffdshow codec for example.

  • Page 35: A Regulatory Compliance

    HDC-301MS Video Capture Card Appendix Regulatory Compliance Page 27...
  • Page 36 HDC-301MS Video Capture Card DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.

  • Page 37: B Hazardous Materials Disclosure

    HDC-301MS Video Capture Card Appendix Hazardous Materials Disclosure Page 29...
  • Page 38 HDC-301MS Video Capture Card B.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 39 HDC-301MS Video Capture Card Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery O: This toxic or hazardous substance is contained in all of the homogeneous materials for the part is below...
  • Page 40 HDC-301MS Video Capture Card 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。 Page 32...
