PCIE-Q470 Full-size PICMG 1.3 CPU Card
MODEL:
PCIE-Q470
Full-size PICMG 1.3 CPU Card supports LGA1200 10th/11th
Generation Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron®
Processor with Intel® Q470/Q470E, DDR4, HDMI, Dual Intel®
2.5GbE, USB 3.2, SATA6Gb/s, M.2, iAUDIO and RoHS
User Manual
Page 1
Rev. 1.00 – May 18, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCIE-Q470 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology PCIE-Q470

Summary of Contents for IEI Technology PCIE-Q470

  • Page 1 PCIE-Q470 Full-size PICMG 1.3 CPU Card MODEL: PCIE-Q470 Full-size PICMG 1.3 CPU Card supports LGA1200 10th/11th Generation Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron® Processor with Intel® Q470/Q470E, DDR4, HDMI, Dual Intel® 2.5GbE, USB 3.2, SATA6Gb/s, M.2, iAUDIO and RoHS User Manual Page 1 Rev.
  • Page 2 PCIE-Q470 Full-size PICMG 1.3 CPU Card Revision Date Version Changes May 18, 2022 1.00 Initial release Page 2...
  • Page 3 PCIE-Q470 Full-size PICMG 1.3 CPU Card Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.
  • Page 4 PCIE-Q470 Full-size PICMG 1.3 CPU Card Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Table of Contents 1 INTRODUCTION ......................12 1.1 I ......................13 NTRODUCTION 1.2 F ......................... 14 EATURES 1.3 C ......................15 ONNECTORS 1.4 D ......................16 IMENSIONS 1.5 D ......................17 1.6 T ..................18...
  • Page 6 PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.12 LAN Link LED Connector ................40 3.2.13 M.2 A-key slot ....................41 3.2.14 M.2 B-key slot ....................43 3.2.15 M.2 M-key slot (on solder side) ..............45 3.2.16 On-Board Power Switch ................47 3.2.17 DDR4 DIMM Slots ..................
  • Page 7 PCIE-Q470 Full-size PICMG 1.3 CPU Card 4.7.1 SATA Drive Connection ................... 77 4.8 S ..................79 OFTWARE NSTALLATION 4.8.1 Driver Download ..................... 79 ® 4.9 I AMT S ................81 NTEL ETUP ROCEDURE A REGULATORY COMPLIANCE ................82 B PRODUCT DISPOSAL ....................84 C ERROR BEEP CODE ....................
  • Page 8 PCIE-Q470 Full-size PICMG 1.3 CPU Card List of Figures Figure 1-1: PCIE-Q470 ........................13 Figure 1-2: Connectors ........................15 Figure 1-3: PCIE-Q470 Dimensions (mm) ..................16 Figure 1-4: Data Flow Diagram ....................17 Figure 3-1: Peripheral Interface Connectors ................26 Figure 3-2: ATX CPU 12V Power Connector Location ..............29 Figure 3-3: Battery Connector Location ..................30...
  • Page 9 PCIE-Q470 Full-size PICMG 1.3 CPU Card Figure 3-28: External Peripheral Interface Connector ..............58 Figure 3-29: LAN Location ......................59 Figure 3-30: LAN LED Location ....................59 Figure 3-31: HDMI Connector ......................60 Figure 3-32: USB 3.2 Gen 1 Connectors (Type-A) ..............61 Figure 3-33: USB 3.2 Gen 2 Type-C Port Location ..............62 Figure 4-1: Disengage the CPU Socket Load Lever ..............66...
  • Page 10 PCIE-Q470 Full-size PICMG 1.3 CPU Card List of Tables Table 1-1: PCIE-Q470 Specifications ..................20 Table 2-1: Packing List .........................23 Table 2-2: Optional Items ......................24 Table 3-1: Peripheral Interface Connectors ................28 Table 3-2: External Peripheral Connectors ................28 Table 3-3: ATX CPU 12V Power Connector Pinouts ..............29 Table 3-4: Chassis Intrusion Connector Pinouts ..............31...
  • Page 11 PCIE-Q470 Full-size PICMG 1.3 CPU Card Table 3-29: HDMI Connector Pinouts ..................60 Table 3-30: External USB 3.2 Gen 1 Connectors (Type-A) Pinouts .........61 Table 3-31: USB 3.2 Gen 2 Type-C Port Pinouts ...............62 Table 4-1: AT/ATX Power Mode Switch Settings ...............72 Table 4-2: BIOS Switch Settings ....................73...

  • Page 12: Introduction

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Chapter Introduction Page 12...

  • Page 13: Ntroduction

    1.1 Introduction Figure 1-1: PCIE-Q470 The PCIE-Q470 is a full-size PICMG 1.3 CPU card. It accepts a Socket LGA1200 10th/11th Generation Intel® Core™ i9/i7/i5/i3, Pentium® or Celeron® processor and supports four 288-pin 2933MHz dual-channel DDR4 DIMMs up to 128 GB. The integrated Intel®...

  • Page 14: Features

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 1.2 Features The PCIE-Q470 motherboard features are listed below: ▪ Full-size PICMG 1.3 CPU card ▪ LGA1200 10th/11th Generation Intel® Core™ i9/i7/i5/i3, Pentium® or Celeron® processor supported ▪ Intel® Q470/Q470E chipset ▪ Four 288-pin 2933 MHz dual-channel unbuffered DDR4 SDRAM DIMMs supported up to 128 GB Intel®...

  • Page 15: Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 1.3 Connectors The connectors on the PCIE-Q470 are shown in the figure below. Figure 1-2: Connectors Page 15...

  • Page 16: Dimensions

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 1.4 Dimensions The main dimensions of the PCIE-Q470 are shown in the diagram below. Figure 1-3: PCIE-Q470 Dimensions (mm) Page 16...

  • Page 17: Data Flow

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 1.5 Data Flow Figure 1-4 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-4: Data Flow Diagram Page 17...

  • Page 18: Technical Specifications

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 1.6 Technical Specifications The PCIE-Q470 technical specifications are listed below. 74 7H Specification/Model PCIE-Q470 Full-size PICMG 1.3 CPU Card Form Factor LGA1200 10th/11th Generation Intel® Core™ i9/i7/i5/i3, CPU Supported Pentium® or Celeron® CPU Intel® Q470/Q470E...
  • Page 19 PCIE-Q470 Full-size PICMG 1.3 CPU Card Fintek F81966D-I Super I/O Controller ENE KB9068QB Embedded Controller Software programmable supports 1~255 sec. system Watchdog Timer reset I/O Interface Connectors 1 x Chassis intrusion (1x2 pin) Chassis Intrusion 1 x 12-bit digital I/O (2x7 pin)

  • Page 20: Table 1-1: Pcie-Q470 Specifications

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Environmental and Power Specifications AT/ATX power support Power Supply 3.3V@1.04A, 5V@8.61A, 12V@12.33A (Intel® Core™ i9-11900K CPU with 4 GB 3200 MHz Power Consumption DDR4 memory) 0ºC ~ 60ºC Operating Temperature -30ºC ~ 70ºC Storage Temperature...

  • Page 21: Packing List

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Chapter Packing List Page 21...

  • Page 22: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the PCIE-Q470 is unpacked, please do the following: ▪ Follow the anti-static guidelines above.

  • Page 23: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the PCIE-Q470 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 24: Optional Items

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 2.4 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image Dual-port USB cable with bracket (P/N: CB-USB02-RS) SATA power cable (P/N: 32102-000100-200-RS) RS-232 cable, 200mm, P=2.0...

  • Page 25: Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Chapter Connectors Page 25...

  • Page 26: Peripheral Interface Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.1 Peripheral Interface Connectors This chapter details all the peripheral interface connectors. 3.1.1 PCIE-Q470 Layout The figure below shows all the peripheral interface connectors. Figure 3-1: Peripheral Interface Connectors Page 26...

  • Page 27: Peripheral Interface Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label 8-pin Molex power ATX CPU 12V power connector CPU12V1 connector Battery connector 2-pin wafer BAT1 Chassis intrusion connector...

  • Page 28: External Interface Panel Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Connector Type Label CHA_DIMM0, CHA_DIMM1 DDR4 DIMM slots 288-pin socket CHB_DIMM0, CHB_DIMM1 S_ATA3, S_ATA4, SATA 6Gb/s connectors 7-pin SATA connector S_ATA5, S_ATA6, RS-232 serial port connectors 10-pin box header COM1, COM2 RS-422/485 serial port connectors...

  • Page 29: Internal Peripheral Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2 Internal Peripheral Connectors The section describes all of the connectors on the PCIE-Q470. 3.2.1 CPU 12V Power Connector CN Label: CPU12V1 CN Type: 8-pin Molex power connector, p=4.2 mm CN Location: See Figure 3-2...

  • Page 30: Battery Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.2 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. NOTE: It is recommended to attach the RTC battery onto the system chassis in which the PCIE-Q470 is installed.

  • Page 31: Chassis Intrusion Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.3 Chassis Intrusion Connector CN Label: CHASSIS1 CN Type: 2-pin header, p=2.54 mm CN Location: See Figure 3-4 CN Pinouts: See Table 3-4 The chassis intrusion connector is for a chassis intrusion detection sensor or switch that detects if a chassis component is removed or replaced.

  • Page 32: Digital Input/Output Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.4 Digital Input/Output Connector CN Label: DIO1 CN Type: 14-pin header, p=2.00 mm CN Location: See Figure 3-5 CN Pinouts: See Table 3-5 The digital I/O connector provides programmable input and output for external devices.

  • Page 33: Ec Debug Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.5 EC Debug Connector CN Label: DBG_SPI1 CN Type: 6-pin wafer, p=1.25 mm CN Location: See Figure 3-6 CN Pinouts: See Table 3-6 The EC debug connector is used for EC debug. Figure 3-6: EC Debug Connector Location...

  • Page 34: Fan Connectors (Cpu)

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.6 Fan Connectors (CPU) CN Label: CPU_FAN1 CN Type: 4-pin wafer, p=2.54 mm CN Location: See Figure 3-7 CN Pinouts: See Table 3-7 The fan connector attaches to a CPU cooling fan. Figure 3-7: CPU Fan Connector Location...

  • Page 35: Fan Connectors (System)

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.7 Fan Connectors (System) CN Label: SYS_FAN1 CN Type: 4-pin wafer, p=2.54 mm CN Location: See Figure 3-8 CN Pinouts: See Table 3-8 The fan connector attaches to a system cooling fan. Figure 3-8: System Fan Connector Location...

  • Page 36: Audio Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.8 Audio Connector CN Label: J_AUDIO1 CN Type: 10-pin header, p=2.00 mm CN Location: See Figure 3-9 CN Pinouts: See Table 3-9 This connector allows connection to an external audio kit. Figure 3-9: Audio Connector Location...

  • Page 37: Front Panel Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.9 Front Panel Connector CN Label: F_PANEL1 CN Type: 14-pin header, p=2.54 mm CN Location: See Figure 3-10 CN Pinouts: See Table 3-10 The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.

  • Page 38: I 2 C Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.10 I C Connector CN Label: I2C1 CN Type: 4-pin wafer, p=1.25 mm CN Location: See Figure 3-11 CN Pinouts: See Table 3-11 The I C connector is used to connect I C-bus devices to the motherboard.

  • Page 39: Smbus Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.11 SMBus Connector CN Label: SMB1 CN Type: 4-pin wafer, p=1.25 mm CN Location: See Figure 3-12 CN Pinouts: See Table 3-12 The SMBus (System Management Bus) connector provides low-speed system management communications. Figure 3-12: SMBus Connector Location...

  • Page 40: Lan Link Led Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.12 LAN Link LED Connector CN Label: LED_LAN1, LED_LAN2 CN Type: 2-pin header, p=2.54 mm CN Location: See Figure 3-13 CN Pinouts: See Table 3-13 The LAN LED connectors are used to connect to the LAN LED indicators on the chassis to indicate users the link activities of the two LAN ports.

  • Page 41: A-Key Slot

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.13 M.2 A-key slot CN Label: M2_A1 CN Type: A-key slot CN Location: See Figure 3-14 CN Pinouts: See Table 3-14 The M.2 2230 slot is keyed in the A position. The M.2 slot supports PCIe x1 and USB 2.0 interfaces.

  • Page 42: Table 3-14: M.2 A-Key (2230) Slot Pinouts

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Description Description PETP0 PETN0 PERP0 PERN0 PCIE_CLK+ PCIE_CLK- PLT_RST CLKREQ0# Pull up PCIE_WAKE W_DIS I2C_DAT I2C_CLK +3.3V +3.3V +3.3V Table 3-14: M.2 A-key (2230) Slot Pinouts Page 42...

  • Page 43: B-Key Slot

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.14 M.2 B-key slot CN Label: M2_B1 CN Type: B-key slot CN Location: See Figure 3-15 CN Pinouts: See Table 3-15 The M.2 2230 slot is keyed in the A position. The M.2 slot supports PCIe x1 and USB 2.0 interfaces.

  • Page 44: Table 3-15: M.2 B-Key (3042/3052/2242/2280) Slot Pinouts

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Description Description PETP0 PETN0 PERP0 PERN0 PCIE_CLK+ PCIE_CLK- PLT_RST CLKREQ0# Pull up PCIE_WAKE W_DIS I2C_DAT I2C_CLK +3.3V +3.3V +3.3V Table 3-15: M.2 B-key (3042/3052/2242/2280) Slot Pinouts Page 44...

  • Page 45: M-Key Slot (On Solder Side)

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.15 M.2 M-key slot (on solder side) CN Label: M2_M1 CN Type: M-key slot CN Location: See Figure 3-16 CN Pinouts: See Table 3-16 The M.2 2280 slot is keyed in the B position. The M.2 slot supports PCIe x2 interfaces.

  • Page 46: Table 3-16: M.2 M-Key (2242/2280) Slot Pinouts

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Description Description PERN1 +3.3V PERP1 PETN1 PETP1 PERN2 PERP2 PETN2 PETP2 DEVSLP PERN3 PERP3 PETN3 PETP3 PERST# CLKREQ PCIECLKN PEWAKE PCIECLKP Module Key Module Key Module Key Module Key Module Key Module Key Module Key...

  • Page 47: On-Board Power Switch

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.16 On-Board Power Switch CN Label: PWR_SW1 CN Type: Push button CN Location: See Figure 3-17 The on-board power button controls system power. Figure 3-17: Power Button Location 3.2.17 DDR4 DIMM Slots CN Label:...

  • Page 48: Sata 6Gb/S Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Figure 3-18: DDR4 DIMM Socket Locations 3.2.18 SATA 6Gb/s Connectors CN Label: S_ATA3, S_ATA4, S_ATA5, S_ATA6 CN Type: 7-pin SATA connector CN Location: See Figure 3-19 CN Pinouts: See Table 3-17 The SATA drive connectors can be connected to SATA drives and support up to 6Gb/s data transfer rate.

  • Page 49: Rs-232 Serial Port Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Figure 3-19: SATA 6Gb/s Connector Locations Description SATA_TX+ SATA_TX- SATA_RX- SATA RX+ Table 3-17: SATA 6Gb/s Connector Pinouts 3.2.19 RS-232 Serial Port Connectors CN Label: COM1, COM2 CN Type: 10-pin box header, p=2.00 mm...

  • Page 50: Rs-422/485 Serial Port Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Figure 3-20: RS-232 Serial Port Connector Location Description Description Table 3-18: RS-232 Serial Port Connector Pinouts 3.2.20 RS-422/485 Serial Port Connectors CN Label: COM3, COM4 CN Type: 4-pin wafer, p=2.00 mm CN Location: See Figure 3-21...

  • Page 51: Figure 3-21: Rs-422/485 Serial Port Connectors Location

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Figure 3-21: RS-422/485 Serial Port Connectors Location Description Description RXD422- TXD422+/TXD485+ RXD422+ TXD422-/TXD485- Table 3-19: RS-422/485 Serial Port Connectors Pinouts Use the optional RS-422/485 cable to connect to a serial device. The pinouts of the DB-9 connector are listed below.

  • Page 52: Flash Spi Rom Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.21 Flash SPI ROM Connector CN Label: JSPI1 CN Type: 6-pin wafer, p=1.25 mm CN Location: See Figure 3-22 CN Pinouts: See Table 3-21 The Flash SPI ROM connector is used to flash the SPI ROM.

  • Page 53: Flash Ec Rom Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.22 Flash EC ROM Connector CN Label: JEC1 CN Type: 8-pin header, p=1.27 mm CN Location: See Figure 3-23 CN Pinouts: See Table 3-22 The Flash EC ROM connector is used to flash the EC ROM.

  • Page 54: Sim Card Slot

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.23 SIM Card Slot CN Label: SIM1 CN Type: SIM slot CN Location: See Figure 3-24 CN Pinouts: See Table 3-23 The SIM card slot enables a SIM expansion module to be connected to the board.

  • Page 55: Internal Usb 2.0 Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.24 Internal USB 2.0 Connectors CN Label: JUSB3, JUSB4, JUSB5 CN Type: 8-pin header, p=2.54 mm CN Location: See Figure 3-25 CN Pinouts: See Table 3-24 The Internal USB 2.0 connectors connect to USB 2.0 devices. Each pin header provides two USB 2.0 ports.

  • Page 56: Internal Usb 3.2 Gen 1 Connector (Type-A)

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.25 Internal USB 3.2 Gen 1 Connector (Type-A) CN Label: USB1 CN Type: USB 3.2 Gen 1 Type-A Port CN Location: See Figure 3-26 CN Pinouts: See Table 3-25 The Internal USB 3.2 Gen 1 connector connects to USB 3.2 devices. This connector provides USB 3.2 Gen 1 (5Gb/s) ports.

  • Page 57: Internal Usb 3.2 Gen 1 Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.2.26 Internal USB 3.2 Gen 1 Connector CN Label: JUSB3-1 CN Type: 20-pin box header, p=2.00 mm CN Location: See Figure 3-27 CN Pinouts: See Table 3-26 The Internal USB 3.2 Gen 1 connector connects to USB 3.2 devices.

  • Page 58: External Peripheral Interface Connector Panel

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.3 External Peripheral Interface Connector Panel The figure below shows the external peripheral interface connector (EPIC) panel. The EPIC panel consists of the following: Figure 3-28: External Peripheral Interface Connector Page 58...

  • Page 59: External 2.5Gbe Rj-45 Connectors

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.3.1 External 2.5GbE RJ-45 connectors CN Label: LAN1, LAN2 CN Type: RJ-45 CN Location: See Figure 3-29 CN Pinouts: See Table 3-27 Each LAN connector connects to a local network. LAN LED location and pinouts see Figure 3-30 and Table 3-28.

  • Page 60: External Hdmi Connector

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.3.2 External HDMI connector CN Label: HDMI1 CN Type: HDMI connector CN Location: See Figure 3-31 CN Pinouts: See Table 3-29 The HDMI connector can connect to an HDMI device. Description Description HDMI_DATA2 HDMI_CLK#...

  • Page 61: External Usb 3.2 Gen 1 Connectors (Type-A)

    CN Pinouts: See Table 3-30 There are two external USB 3.2 Gen 1 ports on the PCIE-Q470. The USB connector can be connected to a USB 2.0 or USB 3.2 device. The pinouts of USB 3.2 Gen 1 connectors are shown below.

  • Page 62: External Usb 3.2 Gen 2 Connector (Type-C)

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 3.3.4 External USB 3.2 Gen 2 Connector (Type-C) CN Label: CON1 CN Type: USB 3.2 Gen 2 Type-C CN Location: See Figure 3-33 CN Pinouts: See Table 3-31 The USB 3.2 Gen 2 connector can be connected to a USB Type-C device.

  • Page 63: Installation

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Chapter Installation Page 63...

  • Page 64: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the PCIE-Q470. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the PCIE-Q470 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 65 This helps to prevent potential ESD damage. Turn all power to the PCIE-Q470 off: ▪ When working with the PCIE-Q470, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system.

  • Page 66: Socket Lga1200 Cpu Installation

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 4.3 Socket LGA1200 CPU Installation WARNING: CPUs are expensive and sensitive components. When installing the CPU please be careful not to damage it in anyway. Make sure the CPU is installed properly and ensure the correct cooling kit is properly installed.

  • Page 67: Figure 4-2: Remove Protective Cover

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Figure 4-2: Remove Protective Cover Step 3: Inspect the CPU socket. Make sure there are no bent pins and make sure the socket contacts are free of foreign material. If any debris is found, remove it with compressed air.

  • Page 68: Figure 4-3: Insert The Socket Lga1200 Cpu

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Step 7: Insert the CPU. Gently insert the CPU into the socket. If the CPU pins are properly aligned, the CPU should slide into the CPU socket smoothly. See Figure 4-3. Figure 4-3: Insert the Socket LGA1200 CPU Step 8: Close the CPU socket.

  • Page 69: Socket Lga1200 Cooling Kit Installation

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Step 9: Connect the 12 V power to the board. Connect the 12 V power from the power supply to the board. Step 0: 4.4 Socket LGA1200 Cooling Kit Installation WARNING: DO NOT attempt to install a push-pin cooling fan.

  • Page 70: Figure 4-5: Cooling Kit Support Bracket

    Do not overtighten the screws. Step 5: Connect the fan cable. Connect the cooling kit fan cable to the CPU fan connector on the PCIE-Q470. Carefully route the cable and avoid heat generating chips and fan blades.Step 0:...

  • Page 71: Dimm Installation

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 4.5 DIMM Installation To install a DIMM, please follow the steps below and refer to Figure 4-6. Figure 4-6: DIMM Installation Step 1: Open the DIMM socket handles. Open the two handles outwards as far as they can.

  • Page 72: System Configuration

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 4.6 System Configuration The system configuration should be performed before installation. 4.6.1 AT/ATX Power Mode Setting The AT and ATX power mode selection is made through the AT/ATX power mode switch which is shown in Figure 4-7.

  • Page 73: Bios Selection Switch

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 4.6.2 BIOS Selection Switch The BIOS selection is made through the BIOS switch which is shown in Figure 4-8. Figure 4-8: BIOS Switch Locations Description Description BIOS1: four PCIe BIOS2: one PCIe Short A - B...

  • Page 74: Clear Cmos Button

    Figure 4-9: Clear CMOS Button Location 4.6.4 PCIe x16 Channel Mode Setup The PCIE-Q470 supports one PCIe x16 interface on the backplane. The PCIe x16 channel mode setup is made through the BIOS menu in “Chipset → System Agent (SA) Configuration →...

  • Page 75: Flash Descriptor Security Override Jumper

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 4.6.5 Flash Descriptor Security Override Jumper The flash descriptor security override jumper (J_FLASH1) allows to enable or disable the ME firmware update. Refer to Table 4-4 and Figure 4-10 for the jumper location and settings.

  • Page 76: Usb Power Selection

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 4.6.6 USB Power Selection The USB power selection is made through the BIOS menu in “Chipset → PCH-IO Configuration”. Use the USB Power SW1 and the USB Power SW2 BIOS options to configure the correspondent USB ports (see Table 4-5) and refer to Table 4-6 to select the USB power source.

  • Page 77: Internal Peripheral Device Connections

    This section outlines the installation of peripheral devices to the onboard connectors. 4.7.1 SATA Drive Connection The PCIE-Q470 is shipped with one SATA drive cables. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors.

  • Page 78: Figure 4-12: Sata Power Drive Connection

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Figure 4-12: SATA Power Drive Connection The SATA power cable can be bought from IEI. See Optional Items in Section 2.4. Page 78...

  • Page 79: Software Installation

    PCIE-Q470 Full-size PICMG 1.3 CPU Card 4.8 Software Installation All the drivers for the PCIE-Q470 are available on IEI Resource Download Center (https://download.ieiworld.com). Type PCIE-Q470 and press Enter to find all the relevant software, utilities, and documentation. Figure 4-13: IEI Resource Download Center 4.8.1 Driver Download...
  • Page 80 PCIE-Q470 Full-size PICMG 1.3 CPU Card Step 3: Click the driver file name on the page and you will be prompted with the  following window. You can download the entire ISO file ( ), or click the small ...

  • Page 81: Intel ® Amt Setup Procedure

    4.9 Intel ® AMT Setup Procedure The PCIE-Q470 is featured with the Intel® Active Management Technology (AMT). To enable the Intel® AMT function, follow the steps below. Step 1: Make sure at least one of the memory sockets is installed with a DDR4 DIMM.

  • Page 82: A Regulatory Compliance

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Appendix Regulatory Compliance Page 82...
  • Page 83 PCIE-Q470 Full-size PICMG 1.3 CPU Card DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply.

  • Page 84: B Product Disposal

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Appendix Product Disposal Page 84...
  • Page 85 PCIE-Q470 Full-size PICMG 1.3 CPU Card CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. ▪ Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 86: C Error Beep Code

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Appendix Error Beep Code Page 86...

  • Page 87: Pei Beep Codes

    PCIE-Q470 Full-size PICMG 1.3 CPU Card C.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found...

  • Page 88: D Hazardous Materials Disclosure

    PCIE-Q470 Full-size PICMG 1.3 CPU Card Appendix Hazardous Materials Disclosure Page 88...

  • Page 89: Rohs Ii Directive (2015/863/Eu)

    PCIE-Q470 Full-size PICMG 1.3 CPU Card D.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 90: China Rohs

    PCIE-Q470 Full-size PICMG 1.3 CPU Card D.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572- 2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。...
