- Page 1 HDC-301EL Video/Audio Capture Card MODEL: HDC-301EL-R10 PCI Express Video/Audio Capture Card with One HDMI Input Channel and One HDMI Output Channel, 1920x1080@30p, H.264 Hardware Encoder User Manual Page i Rev. 1.01 – September 2, 2015...
- Page 2 HDC-301EL Video/Audio Capture Card Revision Date Version Changes September 2, 2015 1.01 Added Chapter 5: FAQ Updated Section 3.2: Driver Installation April 2, 2015 1.00 Initial release Page ii...
- Page 3 HDC-301EL Video/Audio Capture Card Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 4 HDC-301EL Video/Audio Capture Card Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.
-
Page 5: Table Of Contents
HDC-301EL Video/Audio Capture Card Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 F ........................3 EATURES 1.3 A ......................3 PPLICATIONS 1.4 C ..................... 4 ONNECTOR VERVIEW 1.5 S ......................5 PECIFICATIONS 1.6 D ....................... 7 IMENSIONS 2 HARDWARE INSTALLATION................... - Page 6 HDC-301EL Video/Audio Capture Card A REGULATORY COMPLIANCE ................32 B HAZARDOUS MATERIALS DISCLOSURE ............34 B.1 H IPB P AZARDOUS ATERIAL ISCLOSURE ABLE FOR RODUCTS ERTIFIED AS HS C 2002/95/EC W ........35 OMPLIANT NDER ITHOUT ERCURY Page vi...
- Page 7 HDC-301EL Video/Audio Capture Card List of Figures Figure 1-1: HDC-301EL Video/Audio Capture Card..............2 Figure 1-2: HDC-301EL Connector Overview ................4 Figure 1-3: HDC-301EL Dimensions (mm) ...................7 Figure 2-1: HDC-301EL Installation.....................12 Figure 2-2: HDMI Devices Connect to the Video/Audio Capture Card ........13 Figure 3-1: InstallShield Wizard Welcome Window ..............16 Figure 3-2: Ready to Install the Program ...................16 Figure 3-3: Installation Status .....................17...
-
Page 8: List Of Tables
HDC-301EL Video/Audio Capture Card List of Tables Table 1-1: Specifications .......................7 Table 2-1: Package List Contents ....................10 Page viii... -
Page 9: Introduction
HDC-301EL Video/Audio Capture Card Chapter Introduction Page 1... -
Page 10: Overview
HDC-301EL Video/Audio Capture Card 1.1 Overview Figure 1-1: HDC-301EL Video/Audio Capture Card The low power HDC-301EL video/audio capture card supports 1080p Full HD video via HDMI connection. The HDC-301EL video/audio capture card is equipped with the high-performing codec component with one HDMI input channel and one HDMI output channel. -
Page 11: Features
HDC-301EL Video/Audio Capture Card 1.2 Features Some of the HDC-301EL video/audio capture card features are listed below. Encoding up to 1920x1080@30p HDMI input channel with 1920x1080@60p Pass through for transmitting uncompressed video up to 1080p resolution Capture or record HD video in H.264 format Reduce the amount of hard disk space needed by real-time H.264 recording compression capability Low power consumption... -
Page 12: Connector Overview
HDC-301EL Video/Audio Capture Card 1.4 Connector Overview NOTE: The other connectors, jumpers and interfaces on the board not specified below are for R&D diagnostic purposes and should not be used by the end user. The HDC-301EL comes with one HDMI input connector and one HDMI output connector. A PCIe edge connector on the bottom of the capture card enables the HDC-301EL to interface with a motherboard. -
Page 13: Specifications
HDC-301EL Video/Audio Capture Card 1.5 Specifications The HDC-301EL specifications are listed in the table below: HDC-301EL PCI Express x1 PC Interface INPUT PORT Video Input Channel Video Input Type HDMI Audio Input Channel HDMI (stereo) Audio Input Type NO DELAY HDMI PASSTHROUGH Video Output Channel HDMI Video Output Type... - Page 14 HDC-301EL Video/Audio Capture Card 1920x1080 24p/25p/30p 1440x900 1360x768 1280x1024 30p 1280x800 1280x768 Recording Resolution 1280x720 50p/60p 1024x768 800x600 720x576 720x480 640x480 AUDIO PROCESSING 44.1 k, 48 kHz Sampling Frequencies MPEG-4 AAC Audio Compression 128 kbps Recording Bitrate FUNCTIONALITY 8 channels Multiple Card Support Video scaling down compression Scaling...
-
Page 15: Dimensions
HDC-301EL Video/Audio Capture Card OTHERS 83.8 mm x 68.9 mm Dimensions (WxH) Operating Temperature 0ºC ~ 60ºC (32ºF ~ 140ºF), non-condensing 4.5 W Power Consumption Table 1-1: Specifications 1.6 Dimensions The dimensions for the HDC-301EL are listed below. Figure 1-3: HDC-301EL Dimensions (mm) Page 7... -
Page 16: Hardware Installation
HDC-301EL Video/Audio Capture Card Chapter Hardware Installation Page 8... -
Page 17: Unpacking
HDC-301EL Video/Audio Capture Card 2.1 Unpacking 2.1.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the HDC-301EL may result in permanent damage to the capture card and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the video/audio capture card. -
Page 18: Unpacking Checklist
HDC-301EL Video/Audio Capture Card 2.1.3 Unpacking Checklist NOTE: If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the HDC-301EL from or contact an IEI sales representative directly. -
Page 19: Installation Considerations
HDC-301EL Video/Audio Capture Card 2.2 Installation Considerations NOTE: The following installation notices and installation considerations should be read and understood before installation. All installation notices must be strictly adhered to. Failing to adhere to these precautions may lead to severe damage and injury to the person performing the installation. WARNING: The installation instructions described in this manual should be carefully followed in order to prevent damage to the components and... -
Page 20: Video/Audio Capture Card Installation
HDC-301EL Video/Audio Capture Card Before and during the installation of the HDC-301EL, DO NOT: Remove any of the stickers on the PCB board. These stickers are required for warranty validation. Use the product before verifying all the cables and power connectors are properly connected. -
Page 21: Hdmi Devices Installation
HDC-301EL Video/Audio Capture Card 2.4 HDMI Devices Installation Various HDMI devices can be connected to the HDC-301EL. Video input and video output are all supported. Follow the steps below to connect the HDMI devices to the HDC-301EL. Step 1: Insert the HDMI connector from the cable into the HDMI input connector on the HDC-301EL. -
Page 22: Driver Installation (Windows)
HDC-301EL Video/Audio Capture Card Chapter Driver Installation (Windows) Page 14... -
Page 23: Overview
HDC-301EL Video/Audio Capture Card 3.1 Overview A CD is shipped with the video/audio capture card. The CD contains the driver for the video/audio capture controllers on the card. When the video/audio capture card is installed on the system, the driver must be installed. Failure to install the driver means that the video/audio capture card cannot be detected by the system. -
Page 24: Figure 3-1: Installshield Wizard Welcome Window
HDC-301EL Video/Audio Capture Card Figure 3-1: InstallShield Wizard Welcome Window Step 5: The Ready to Install the Program window appears (Figure 3-2). Click Install to start the installation. Figure 3-2: Ready to Install the Program Page 16... -
Page 25: Figure 3-3: Installation Status
HDC-301EL Video/Audio Capture Card Step 6: The driver starts to install and the screen in Figure 3-3 appears. Figure 3-3: Installation Status Step 7: When the driver installation is complete, click the Finish button to finish driver installation (Figure 3-4). Step 0: Figure 3-4: Installation Complete Page 17... -
Page 26: Hdc-301El Driver
HDC-301EL Video/Audio Capture Card 3.2.2 HDC-301EL Driver To install the HDC-301EL driver, please follow the steps below. If the HDC-301EL driver is already installed, please refer to Section 3.3 to uninstall the driver first. NOTE: If the User Access Control dialog box appears during installation, click Yes to continue. -
Page 27: Figure 3-6: Windows Security Window
HDC-301EL Video/Audio Capture Card Step 5: The following window appears to confirm the installation. Click Install. Figure 3-6: Windows Security Window Step 6: The driver starts to install and the screen in Figure 3-7 appears. Figure 3-7: Driver Installing Step 7: When the driver installation is complete, click the Finish button to finish driver installation. -
Page 28: Figure 3-8: Driver Installation Complete
HDC-301EL Video/Audio Capture Card Figure 3-8: Driver Installation Complete Step 8: Check the Device Manager in the Windows control panel to ensure the HDC-301EL driver has been properly installed. Single Card: Multiple Cards: Figure 3-9: Device Manager Page 20... -
Page 29: Uninstall Driver
HDC-301EL Video/Audio Capture Card NOTE: If the user fails to install the driver by following the above procedure, please install the HDC-301EL driver manually in the Device Manager. To do this, right click HDC-301EL in the Device Manager, and select Update Driver Software. -
Page 30: Iei Hd Capture Ap (Windows)
HDC-301EL Video/Audio Capture Card Chapter IEI HD Capture AP (Windows) Page 22... -
Page 31: Software Installation (Windows)
HDC-301EL Video/Audio Capture Card 4.1 Software Installation (Windows) The HDC-301EL comes with a video capture application – IEI HD Capture AP. This section describes how to install the application in Windows environment. 4.1.1 System Requirements The supported OS versions are listed below: Microsoft Windows 7, 32-bit Microsoft Windows 7, 64-bit After installing the driver, the following programs must be installed in order to use the IEI... -
Page 32: Figure 4-1: Iei Hd Capture Full X86 Setup Wizard Welcome Window
HDC-301EL Video/Audio Capture Card Figure 4-1: IEI HD Capture Full x86 Setup Wizard Welcome Window Step 4: Select a folder for IEI HD Capture AP installation in Figure 4-2. Click Next to continue. Figure 4-2: Select Installation Folder Step 5: The following screen appears. -
Page 33: Figure 4-3: Confirm Installation
HDC-301EL Video/Audio Capture Card Figure 4-3: Confirm Installation Step 6: The system starts installing the IEI HD Capture AP. Figure 4-4: Installing IEI HD Capture AP Step 7: When the IEI HD Capture AP is successfully installed, the following window appears. -
Page 34: Using Iei Hd Capture Application
HDC-301EL Video/Audio Capture Card Figure 4-5: Installation Complete 4.2 Using IEI HD Capture Application The IEI HD Capture AP is a video capture tool that allows user to capture video through the HDMI input ports in Windows environment. To use the IEI HD Capture AP to capture video, follow the steps below. If the older version of the IEI HD Capture AP is already installed, please refer to Section 4.3 to uninstall it. -
Page 35: Figure 4-6: Iei Hd Capture Ap
HDC-301EL Video/Audio Capture Card Figure 4-6: IEI HD Capture AP Step 3: The Encode Setting window appears (Figure 4-7). Make necessary configuration setting by following the guideline below: Audio Enable: check to enable the audio encoding Sample Rate: select the sample rate of the audio Volume: select the volume amount for encoding Video Input Resolution: select a video input resolution which depends on the... -
Page 36: Figure 4-7: Encode Setting
HDC-301EL Video/Audio Capture Card Figure 4-7: Encode Setting Step 4: After finishing the setting configuration, click OK to save the settings. Step 5: To start capture the video, click the Start button on the IEI HD Capture AP user interface. The Save File As window appears. Specify a location to save the encoded video file, and change the file name as necessary. -
Page 37: Uninstall Iei Hd Capture Ap
HDC-301EL Video/Audio Capture Card Figure 4-8: IEI HD Capture AP – Stop Button 4.3 Uninstall IEI HD Capture AP To uninstall the IEI HD Capture AP, follow the steps below. Step 1: Select Control Panel Programs Programs and Features. Step 2: Select IEI HD Capture AP and click the Uninstall button. -
Page 38: Faq
HDC-301EL Video/Audio Capture Card Chapter Page 30... - Page 39 HDC-301EL Video/Audio Capture Card Capture card, driver, application and input source are all ready, but the recorded video is not displayed or displayed incorrectly. In this situation, a H.264 video codec must be installed to display the recorded video -- the ffdshow codec for example.
-
Page 40: Regulatory Compliance
HDC-301EL Video/Audio Capture Card Appendix Regulatory Compliance Page 32... - Page 41 HDC-301EL Video/Audio Capture Card DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.
- Page 42 HDC-301EL Video/Audio Capture Card Appendix Hazardous Materials Disclosure Page 34...
- Page 43 HDC-301EL Video/Audio Capture Card B.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
- Page 44 HDC-301EL Video/Audio Capture Card Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery O: This toxic or hazardous substance is contained in all of the homogeneous materials for the part is below...
- Page 45 HDC-301EL Video/Audio Capture Card 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。 Page 37...
