IPCIE-4POE
PCIe Power over Ethernet Card
PCIe PoE 轉接卡
Quick Installation Guide/快速安裝指南
Version 1.02
Features / 產品特色
Quad-port 1000BASE-T Power over Ethernet (PoE)
支援四埠 1000BASE-T PoE 乙太網路供電
Intel® I210AT Ethernet controller
Intel® I210AT 乙太網路控制器
IEEE 802.3af compliant
符合 IEEE 802.3af 規範
Support link aggregation/jumbo frames (9 kB)
支援鏈路聚合 / 巨型封包(9 kB)
Packing List / 內容清單
1 x IPCIE-4POE card / IPCIE-4POE 轉接卡
1 x QIG (Quick Installation Guide) / 快速安裝指南
Advertisement
Related Manuals for IEI Technology IPCIE-4POE
Summary of Contents for IEI Technology IPCIE-4POE
- Page 1 Intel® I210AT 乙太網路控制器 IEEE 802.3af compliant 符合 IEEE 802.3af 規範 Support link aggregation/jumbo frames (9 kB) 支援鏈路聚合 / 巨型封包(9 kB) Packing List / 內容清單 1 x IPCIE-4POE card / IPCIE-4POE 轉接卡 1 x QIG (Quick Installation Guide) / 快速安裝指南...
- Page 2 警告！ 安裝前請務必將電腦的電源線拔除，否則可能會造成系統損毀與人身傷害。 ------------------------------------------------------------------------------------------------------------------------------- 1. Turn off the computer that you will install the IPCIE-4POE, and remove the power cord. Then, open the system chassis. 請將要安裝 IPCIE-4POE 的電腦關機並將電源線拔除，再將機殼打開。 2. Locate an empty PCIe x4 slot. Remove the blank bracket panel that aligns with the empty PCIe slot.
- Page 3 Connector Pinouts / 連接器腳位定義 PWR1: Internal power connector Description Description Power in Power in J1: External power connector Description Description Power in PLAN1: Quad-port LAN connector Description Description MDIA0+ MDIA0- MDIA1+ MDIA2+ MDIA2- MDIA1- MDIA3+ MDIA3- Description Description On: linked Off: 10 Mb/s Blinking: data is Green: 100 Mb/s...
- Page 4 Windows XP Windows 8/8.1 Windows 7 Windows 10 Install the driver corresponding to your operating system before using the IPCIE-4POE. The driver can be downloaded from IEI Resource Download Center (https://download.ieiworld.com). IPCIE-4POE 的驅動程式支援下列操作系統： Windows XP ...
