Page 1: Installation Manual
IP Office Installation Manual 40DHB0002USCL – Issue 9 (28th October 2003) -
Page 2: Table Of Contents
Page 2 - Contents Contents Introduction ...5 General ...5 Scope of Manual ...5 IP401 Compact Office Platform ...5 General ...6 IP401 Compact Office - Front View...7 Port connections... 7 IP401 Compact Office - Rear View ...8 Port connections... 8 Typical Configuration ... 9 IP403 Office Platform ...10 General ...10 Expansion Modules ... -
Page 3: Contents
IP400 Office Systems ...28 Integral Module Kits ...29 Trunk Module Kits...29 Power Supplies...30 IP Office Rack Mounting Kits ... 31 Expansion Modules...31 Preparing for Installation...32 Introduction ...32 Tools & Parts Required...32 Space requirements...33 Environmental requirements ...33 Power Supply requirements ...34 Grounding...35 Protective Ground ... - Page 4 Page 4 - Contents IP Office Operation in EU ... 62 IP Office Operation in New Zealand ... 62 IP Office Operation in USA ... 62 Technical Data...63 Port Pinouts ...63 Analog Trunk Ports (RJ45) ... 63 Power Fail and POT Ports (RJ45) ... 63 DS/DT Ports (RJ45) ...
-
Page 5: Introduction
IP Office training courses. Ensure that you have read and understood this manual before beginning installation. For installation instructions for the Avaya IP Office - Small Office Edition, refer to the separate Installation Manual (available on CD). -
Page 6: General
The auto-negotiating 10/100 BaseT LAN hub provides access to networks and/or up to eight IP telephones. The DT ports support Avaya 2000 series telephones. DT ports are set to A-Law PCM encoding at default but can be programmed to µ-Law PCM encoding. -
Page 7: Ip401 Compact Office - Front View
Port connections • DT Ports: DT ports are used for connection to Avaya 2000 series telephones (see page 5) and support either A-Law or µ-Law PCM encoding (default A-Law). Using DT Line Cords (see page 68) and standard structured wiring, these RJ45 ports can be extended to the required telephone location. -
Page 8: Ip401 Compact Office - Rear View
Page 8 - IP401 Compact Office - Rear View IP401 Compact Office - Rear View DC Power I/P Socket External O/P Socket Notes: 1. The IP401 Compact Office 4 is shown above; the WAN port is optional. 2. On an IP401 Compact Office 2, the WAN port is optional and BRI 1 is not fitted. -
Page 9: Typical Configuration
A customer requiring a voice and data solution for a warehousing facility remote from a regional office. Three administrators and two pickers staff the warehouse. This configuration provides support for four Avaya 2000 series digital telephones, one for each of the administrators, leaving a spare port for future growth. Up to four analog telephones (POTS), two of which support a DECT wireless solution to allow the pickers freedom of movement, with one of the remaining ports being used for a fax machine. -
Page 10: Ip403 Office Platform
• DT ports - support Avaya 2000 series telephones. • DS ports - support Avaya 6400, 2420 series and/or Avaya 4400 series telephones. Both ports can be set for either µ-Law or A-Law PCM encoding. At default DT ports are set to A-Law and DS ports are set to µ-Law. -
Page 11: Ip403 Office - Front View
DT or DS Ports 1-8 Port connections • DT/DS Ports - DT ports are for connection to Avaya 2000 series telephones (see page 5). - DS ports are for connection to Avaya 4400, 2420 and/or 6400 series telephones (see page 5). -
Page 12: Ip403 Office - Rear View
Page 12 - IP403 Office - Rear View IP403 Office - Rear View DC Power I/P Socket External O/P Socket Port connections • External O/P Socket: Two relay ports that allow externally powered circuits to be controlled via a single 3.5mm stereo jack socket. •... -
Page 13: Typical Configuration
A customer with sophisticated telephony requirements, needing 30 exchange lines and 80 Display Terminals. This configuration provides support for 98 Avaya 20 series digital telephones (18 spare for growth) and a single Primary Rate ISDN connection. If growth beyond 18 users or additional line capacity were anticipated, the IP406 Office would be considered more appropriate. -
Page 14: Ip406 Office Platform
Page 14 - General IP406 Office Platform General The IP406 Office base unit supports up to 180 extensions by using up to 6 Expansion modules. Connection to trunks is via any two of the following integral interface modules as follows:- - Single PRI E1/PRI E1-R2 (30 trunks) or - Single PRI T1 (23B+1D or 24B trunks - USA only) or - Quad BRI (8 trunks) or... -
Page 15: Ip406 Office - Front View
IP406 Office Platform IP406 Office - Front View Expansion Ports 1 Green Status LEDs Port connections • LAN Ports The eight auto-negotiating 10/100 BaseT LAN hub ports are used for PC and server connectivity. They can also be used to connect to the optional IP400 WAN3 Expansion Module (see page 26) and IP telephones. -
Page 16: Ip406 Office - Rear View
Page 16 - IP406 Office - Rear View IP406 Office - Rear View DC Power I/P Socket External O/P Socket Port connections • External O/P Socket: Two relay ports that allow externally powered circuits to be controlled via a single 3.5mm stereo jack socket. •... -
Page 17: Typical Configurations
IP406 Office Platform Typical Configurations Scenario 1: A business requiring 60 analog Telephones and 8 Basic Rate ISDN lines (16 channels). The IP406 Office BRI 16 with two IP400 Office Phone 30 modules provides the required line and extension capacity. Through the use of PhoneManager Lite the functionality provided by the Analog Telephones is greatly enhanced. -
Page 18: Ip412 Office Platform
Page 18 - General IP412 Office Platform General The IP412 Office base unit supports up to 360 extensions by using up to12 Expansion modules. Connection to trunks is via a combination of any of the following integral interface modules :- - Single or Dual PRI E1/PRIE1-R2 (30 or 60 trunks respectively) - Single or Dual PRI T1 (24 or 48 trunks respectively - USA only) - Quad BRI (8 trunks) -
Page 19: Ip412 Office - Front View
IP412 Office Platform IP412 Office - Front View Expansion Ports 1-12 Green Status LEDS Port connections • LAN Ports: The segmented dual independent auto-negotiating 10/100 BaseT Ethernet ports are used for PC and server connectivity. They can also be used to connect to the optional IP400 WAN3 Expansion Module (see page 26) and IP telephones. -
Page 20: Ip412 Office - Rear View
Page 20 - IP412 Office - Rear View IP412 Office - Rear View DC Power I/P Socket External O/P Socket Port connections • External O/P Socket Two relay ports that allow externally powered circuits to be controlled via a single 3.5mm stereo jack socket. -
Page 21: Typical Configurations
IP412 Office PRI 48 T1 6 X IP400 Office Digital Station 30 Module 2 x IP400 Office Analog Trunk 16 180 x Avaya 6412 Digital Terminals IP Office Installation Manual 40DHB0002USCL – Issue 9 (28th October 2003) IP412 Office - Rear View - Page 21... - Page 22 Page 22 - IP412 Office - Rear View Scenario 2: A Business requiring 90 IP hardphones, 90 IP softphones and 60 lines. This configuration illustrates an IP412 Office PRI 60 E1 fitted with two optional IP400 Office Voice Compression Module 20s. These two internally fitted cards allow up 40 simultaneous calls to external parties, as they are only used when an IP extension is calling a non-IP telephone or line.
-
Page 23: Expansion Modules
(1-16). Port connections • DT ports are used for connection to Avaya 2000 series telephones (see page 5) and support either A-Law or µ-Law PCM encoding. Both DT and DS ports can be set for either µ-Law or A-Law PCM encoding. At default both types of port are set to µ-Law but can be switched, in software, to A-Law (refer to the Administration Manager Manual for details). -
Page 24: Ip400 Digital Stations 16/30
The IP400 Digital Station Expansion Module similar to the IP400 Digital Terminal Expansion Module (see page 23) with the exception that the Ports are labeled DS not DT and support Avaya 6400, 2420 or 4400 series telephones. IP400 Phone 8/16/30... -
Page 25: Ip400 So8
Expansion Modules IP400 So8 The So8 Module is only applicable to countries that support the ETSI signaling protocol (see page 31). Front View Green LED Connection OK Phone Ports 1 - 8 Port connections • BRI Ports: These are 64k ISDN BRI S-Bus ports and are used for connection to ISDN Telephones, Group 4 faxes, Video conferencing units, etc. -
Page 26: Ip400 Wan3
Page 26 - IP400 WAN3 IP400 WAN3 Front View Port connections • LAN Port: The LAN Port is the expansion port and permits connection to an IP403, IP406 or IP412 Office platform LAN Port. A LAN Interconnect cable (see page 70) is required for connection to an IP403 or IP406 and an IP412 requires a Crossover cable (see page 72). -
Page 27: Ip400 Analog Trunk 16
Expansion Modules IP400 Analog Trunk 16 Front View Analog Trunk Ports 1-8 Port connections • Analog Trunk Ports: These ports are used for connection to standard analog trunks (loop start or ground start). Using standard structured wiring, these RJ45 ports can be extended to the required trunk sockets. -
Page 28: Country Variants
Page 28 - IP400 Office Systems Country Variants The following are lists of the country variants for each IP400 Office platform, trunk module kits, Integral module kits and expansion modules. The PCS level for each module can be found on a label that is stuck to the base of each module. IP400 Office Systems Throughout this section the following abbreviations are used: = Everywhere... -
Page 29: Integral Module Kits
Country Variants Integral Module Kits Voice Compression Modules (VCM) Variants IP400 VCM 5 expansion kit IP400 VCM 10 expansion kit IP400 VCM 20 expansion kit IP400 VCM 30 expansion kit Dual Modem Module Variants IP400 Modem 2 expansion kit (V.90) Trunk Module Kits BRI Trunk Interface Module Variant... -
Page 30: Power Supplies
Page 30 - Power Supplies Power Supplies Common Lump-in-Line Power Supply units are supplied with each IP Office/Expansion Module. However, the power leads are county specific and must be ordered separately. These power leads only applicable to IP Office base units/Expansions modules and must not be used on the IP Office Small Edition, see the separate Installation Manual for details. -
Page 31: Ip Office Rack Mounting Kits
Country Variants IP Office Rack Mounting Kits Rack Mounting Kit Variant Rack Mounting kit for 19 inch racks Expansion Modules IP400 Phone Variant IP400 Phone 8 IP400 Phone 16 IP400 Phone 30 IP400 Digital Terminals Variant IP400 Digital Terminal 16 IP400 Digital Terminal 30 IP400 Digital Stations Variant... -
Page 32: Preparing For Installation
Page 32 - Introduction Preparing for Installation Introduction This section reviews the requirements for installing an IP Office system. You must meet these requirements for the system to operate safely and in the intended manner. This section covers : – Tools & Parts Required on page 32. –... -
Page 33: Space Requirements
Preparing for Installation Space requirements Check that the planned location meets the following requirements. Height : A IP401 Compact Office module is 71mm (2.8 inches) high. IP403, 406, 412 and all Expansion modules are 71mm(2.8 inches) high. Hence the total height of a system is the number of modules multiplied by 71mm (2.8 inches). -
Page 34: Power Supply Requirements
– UPS Equipment : The use of UPS's to support the IP Office system during mains power failure is highly recommended. Such equipment also provides mains conditioning. Contact Avaya for details of preferred and tested suppliers and models. Page 34 - Preparing for Installation Power Supply requirements connected to a 50/60Hz, 100-240V power source. -
Page 35: Grounding
Preparing for Installation Grounding Provision is made for both protective ground (earthing) and functional ground (earthing). In addition, where the installation of telephone and/or other standard (tip/ring) devices in another building is required, In-Range-Out-Of-Building (IROB) protectors must be fitted (see page 36). Protective Ground A protective ground must be permanently fitted to IP400 Analog Trunk 16 modules (see page 27). -
Page 36: Out Of Building Telephone Installations
Avaya IP400 Phone Barrier Boxes must only be used in conjunction with UL Listed Avaya IP400 Phone 8/16/30 modules. Where more than three Avaya IP400 Phone Barrier boxes are to be used they must be rack mounted (see page 37). For non-rack mounting of the Avaya IP400 Phone Barrier Box, proceed as follows: Notes: 1. -
Page 37: Rack Mounting Barrier Boxes
Preparing for Installation Rack Mounting Barrier Boxes Where more than three Avaya IP400 Phone Barrier Boxes are to be used they must be rack mounted. Rack mounting kits are available (SAP Code 700293905) for mounting eight Avaya IP400 Phone Barrier Boxes. A maximum of 16 Avaya IP400 Phone Barrier Boxes (using two Rack kits) can be connected to one IP400 Phone 30 module. -
Page 38: Installing A New System
Page 38 - Unpacking Installing a New System Unpacking Before proceeding with installation, ensure that you have read the notes covered in Preparing for Installation on page 32. Unpacking and checking : 1. Before unpacking check for any signs of damage that has occurred during transit. If any damage exists bring it to the attention of the carrier. -
Page 39: Initial Assembly
8. Connect the individual Lump-in-Line PSU to each IP Office module and switch on*. 9. From the Administrator CD (see page 47), install on your PC the software required to configure and manage your Avaya IP Office (see page 46). *IMPORTANT: IP Office Installation Manual 40DHB0002USCL –... -
Page 40: Installation Of Integral Modules
Page 40 - Initial Assembly Installation of Integral Modules To install an integral module in an IP Office system, follow the pictorial instructions given below: Trunk Interface Modules (BRI/PRI/ANALOG4) For IP403 see page 12, for IP406 see page 16 and for IP412 see page 20. Procedure 1. -
Page 41: Installation Of Voice Compression Modules (Vcm)
Installing a New System Installation of Voice Compression Modules (VCM) Optional Voice Compression Modules (only one for IP 403/IP406 module and a max. of two for IP412, see pages 10, 14 and 18 respectively) are fitted to an IP Office base unit as follows: Procedure 1. -
Page 42: Dual Modem Module
Page 42 - Initial Assembly Dual Modem Module An optional Dual Modem Module (see pages 10, 14 and 18) is fitted to an IP Office base unit as follows: Procedure 1. Remove the three fixing screws on the rear of cover. 2. -
Page 43: Rack Mounting Assembly Instructions
Installing a New System Rack Mounting Assembly Instructions IP403, 406, 412 and expansion modules can be mounted in any standard 19" rack as follows: CAUTIONS: Elevated Operating Ambient Temperature: If installed in a closed or multi-unit rack assemble, the operating ambient temperature of the rack environment may be greater that the room ambient. -
Page 44: Ip401 Compact Office Wall Mounting
Page 44 - IP401 Compact Office Wall Mounting IP401 Compact Office Wall Mounting All variants of the IP401 Compact Office can be either shelf or wall mounted. Four retaining slots (item secured either: • Horizontally on a shelf - leaving sufficient space for the cabling at both front and rear of the unit. -
Page 45: Ip401 Expansion And Installation Of Integral Modules
Installing a New System IP401 Expansion and Installation of Integral Modules An IP401 Compact Office 2 can be expanded to an IP401 Compact Office 4. Either unit can be expanded with a WAN card. In addition, either or both an optional Voice Compression Module (VCM) and/or a VME module (providing memory capacity for embedded voice mail) can be fitted. -
Page 46: Basic System Programming
Page 46 - Introduction Basic System Programming Introduction This sections covers only the most basic aspects of system programming required to install an IP Office system. When first powered up, all IP Office systems will operate as a simple PBX. However, full system programming is highly dependent on customer requirements. -
Page 47: Initial Programming
6. Installation runs and on completion select Restart now and click Finish twice. The IP Office Administration suite of applications is now installed on your PC and you are now ready to configure your Avaya IP Office. You have two choices: Using the IP Office Installation Wizard: This application is recommended for first time installers. -
Page 48: Using The Ip Office Manager Application
Page 48 - Initial Programming Using the IP Office Manager Application: This application is recommended for experienced installers. From the Program file on your PC, select IP Office and Manager. You will be requested to enter both the Operator Name and Password. This password gains access to the Configuration Tree facilities allocated to the named operator. -
Page 49: Software Upgrades
IP403 and to upgrade to all Software Levels on an IP401, IP406 and IP412, perform the following: Right click on Start and select Explore | Program Files | Avaya | IP Office Manager. Save all xxx.cfg files (where xxx is the name of the configuration) to a separate safe location. - Page 50 12. Do not open the Manager application at this stage. 13. Using the Explorer on your PC open up the Program Files | Avaya | IP Office | Manager | IP403V1_99 folder. This will contain a file called ip403.bin. This file is version 1.99 of the IP Office 403 firmware and contains the loader that is necessary to...
-
Page 51: Telephone Installation
Telephone Installation Telephone Installation Checking Telephones It is preferable to leave connection of telephones until after installation of other IP Office equipment and full system programming has been completed (including the set-up of directory numbers and names). Note that by IP Office telephones we mean devices manufactured and supplied as part of the IP Office product range and not third party telephone devices. -
Page 52: Connecting & Checking Two-Wire Telephones
Page 52 - Checking Telephones Connecting & Checking Two-Wire Telephones All two-wire devices (POTS) should be tested according to the manufacturer's instructions before connection to the IP Office system. Connect the two-wire device and make a test call. Power Fail Telephones and Sockets All power fail sockets (on IP400 Analog Trunk 16 modules only –... -
Page 53: Wall Mounting 2000 Series Telephones
Telephone Installation Wall Mounting 2000 Series Telephones Mounting brackets exist which clip onto the base on IP Office telephones. These brackets (two required per telephone) can be used to either raise the desk position of the telephone or for wall mounting. Before wall mounting a telephone, check that the surface is flat, vertical and not subject to movement or vibration. - Page 54 Page 54 - Wall Mounting 2000 Series Telephones Telephone Installation Page 54 - Telephone Installation IP Office Installation Manual Wall Mounting 2000 Series Telephones 40DHB0002USCL – Issue 9 (28th October 2003)
-
Page 55: Wall Mounting 44/4600, 2420 & 6400 Series Telephones
Telephone Installation Wall Mounting 44/4600, 2420 & 6400 Series Telephones The following pictorial instructions, although for a 4600 telephone, provide a general overview on how to wall mount both series of telephones. For safety instructions and details, refer to the specific instructions for each telephone type (supplied on the CD with the IP Office system). -
Page 56: System Handover
– Has the mains supply (and any UPS if fitted) been tested? – Where VoIP is to be deployed have the appropriate network design criteria and QoS mechanisms been applied as per the Avaya planning guidelines. Wiring : – Have the trunk modules and Analog Trunk 16, where equipped, been fitted with the appropriate functional/protective grounds (see page 35). -
Page 57: Safety And Homologation Statements
24). Refer to page 59 for information concerning which Trunk Interface module variants are fitted in which country. The Avaya IP400 Office units are intended to be installed by 'Service Personnel' and it is the responsibility of the Service Personnel to ensure that all subsidiary... -
Page 58: Electromagnetic Interference Information
Page 58 - Electromagnetic Interference Information Electromagnetic Interference Information Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 59: Trunk Interface Modules
Safety and Homologation Statements Trunk Interface Modules Rest Of World (ROW) To ensure the validation of the approvals in ROW (i.e. EU, Hungary, Australia and New Zealand), only the following interface cards must be installed as detailed in the following IP400 Office products: Product IP403 Office DT... -
Page 60: Further Information And Product Updates
This guide is also available from the Avaya's support web site: Support Telephone Numbers For initial help and support, contact your distributor/supplier. The following contact points are for Avaya authorized partners. In the USA only, Avaya provides a toll-tree Customer Helpline 24 hours a day: Name: Customer Helpline: Address:... -
Page 61: Regulatory Instructions For Use
Safety and Homologation Statements Regulatory Instructions for Use Any changes or modifications not expressly approved by Avaya ECS Ltd could void the user's authority to operate the equipment. IP Office Operation in Australia Connection Connection of IP400 Office products must be via a Line Isolation Unit with a telecommunications compliance label. -
Page 62: Ip Office Operation In Eu
Page 62 - Regulatory Instructions for Use IP Office Operation in EU 1. 999 and 112 calls must not be barred. Doing so will invalidate the approval. 2. All connections at the MDF shall be identifiable by suitable labeling. 3. The CE mark displayed on IP Office equipment indicates the systems compliance with the EMC, LVD, and R&TTE Directives and common technical regulations for Primary Rate and Basic Rate ISDN. -
Page 63: Technical Data
Technical Data Technical Data Port Pinouts This section provides the technical specifications for the IP Office ports with the exception of the USB port and cable. All diagrams are viewed from the front. The USB port and cable (up to 5 meters) are standard. Refer to page 67 for cable details. Note: Throughout the following, Tx = from IP Office and Rx = to IP Office. -
Page 64: Isdn Port - Pri (Rj45)
Page 64 - Port Pinouts ISDN Port – PRI (RJ45) Pin 1 LAN Port – 10/100 BaseT For IP Office 403/406 the information below refers to LAN ports 1 – 7. Port 8 is switchable in software (exchanges Tx and Rx signals). For IP412 and WAN3, both ports have the Rx and Tx connections exchanged. -
Page 65: Audio Port (3.5Mm Stereo Jack Socket)
Technical Data Audio Port (3.5mm Stereo Jack Socket) Left Right Expansion Port (RJ45 Socket) Pin 1 External Control Port (3.5mm Stereo Jack Socket) Control Circuit Control Circuit 1 Control Circuit 2 Each circuit can be switched independently. Switch Setting IP Office Installation Manual 40DHB0002USCL –... -
Page 66: Wan Port (37 Way D-Type Socket)
Page 66 - Port Pinouts WAN Port (37 Way D-Type Socket) Pin 37 Pin No. Description V11 Rx-B V11 Ind-A V11 Clk-A V11 Tx-A V11 Ctl-B V11 Gnd WAN ID 1 V24 DTR V24 Rx V24 TxClk V24 DCD V24 CTS V35 Tx-B V35 SCTE-B V35 Rx-B... -
Page 67: Cables
Technical Data Cables This section provides information about the cables that are used with IP Office. Refer to page 63 for port pin out details. All of the following cables are for internal use only. All structured cabling/site wiring must conform to all local regulations. Cautions: DTE Cable SAP Code.:- 700213432 (25 Way) -
Page 68: Dt Line Cord For Structured Cabling
Page 68 - Cables DT Line Cord for Structured Cabling SAP Code.:- 700047871 A RJ11 Plug. B RJ45 Plug. C Cable. D 4 meters/13.2ft. Pin Connections RJ11 Pin Number Caution: Other connections may be present in cables and or structured cabling. For 4450DS modules, this cable can be used to connect the module’s PSU Line socket and the structured cabling. -
Page 69: Pri/Bri Isdn Cable
Technical Data PRI/BRI ISDN Cable SAP Code:- 700213440 Supply: As standard with IP Office systems. A RJ45 Plug. B RJ45 Plug. C Cat 5 UTP cable - RED. D 3 meters/9.84ft. Pin Connections End A *Rx-A *Rx-B *Tx-A *Tx-B * With reference to the TE. Pins 7 and 8 are through connected for ease of construction. -
Page 70: Lan Interconnect Cable
Page 70 - Cables LAN Interconnect Cable SAP Code:- 700213465 Supply: The cable is supplied with the WAN3 Expansion Module. A RJ45 Plug. B RJ45 Plug. C Cat 5 UTP cable - GREEN. D 1 meter/3.28ft. Pin Connections End A Color White/Orange Orange/White... -
Page 71: Lan Cable
Technical Data LAN Cable SAP Code:- 700213481 A RJ45 Plug. B RJ45 Plug. C Cat 5 UTP cable - GREY. D 3 meters/9.84ft. Pin Connections End A Color White/Orange Orange/White White/Green Green/White Blue/White White/Blue White/Brown Brown/White This cable is used: When connecting IP Office hub ports 1 - 7 directly to a PC. -
Page 72: Lan Crossover Cable
Page 72 - Cables LAN Crossover Cable SAP Code:- 700213473 A RJ45 Plug. B RJ45 Plug. C Cat 5 UTP cross-over cable - BLACK. D 3 meters/9.84ft. Pin Connections End A Color White/Orange Orange/White White/Green Green/White This cable is used when connecting Hub Ports 1 - 7 directly to another Hub and for connecting a WAN3 to an IP412. -
Page 73: Expansion Interconnect Cable
Technical Data Expansion Interconnect Cable SAP Code:- 700213457 Supply: One per Expansion Module. A Shielded RJ45 Plug. B Shielded RJ45 Plug. C STP (Shielded Twisted Pair) cable - BLUE. D 1 meter/3.28ft. Pin Connections End A Name Rx-A Rx-B Sync-A Sync-B Clock-A Clock-B... -
Page 74: V.24/V.28 Wan Cable
Page 74 - Cables V.24/V.28 WAN Cable SAP Code:- 700213416 A 37 Way D-Type Plug with UNC 4-40 locking screws. B 25 Way D-Type Plug with UNC 4-40 locking screws. C Label D 12 core screened cable - each core is 7/0.203mm (24 AWG) tinned copper stranded wire, nominal capacitance of 95pF/m, resistance of 92 Ω/km, screened with tinned copper braid, maximum working voltage of 440V rms and a Maximum current per core of 1A rms... -
Page 75: X.21 Wan Cable
Technical Data X.21 WAN Cable SAP Code:- 700213408 A 37 Way D-Type Plug with UNC 4-40 locking screws. B 15 Way D-Type Plug with M3 locking screws. C Label D 6 twisted pair screened cable - each core is 7/0.203mm (24 AWG) tinned copper stranded wire, nominal capacitance of 98pF/m, impedance of 77 Ω... -
Page 76: Wan Cable
Page 76 - Cables V.35 WAN Cable SAP Code:- 700213424 A 37 Way D-Type Plug with UNC 4-40 locking screws. B 34 Way MRAC Plug. C Label D 10 twisted pair screened cable - each core is 7/0.203mm (24 AWG) tinned copper stranded wire, nominal capacitance of 98pF/m, impedance of 80 Ω... -
Page 77: Telephone Converter Cables
Technical Data Telephone Converter Cables The following diagrams show the pin-outs of various Structured Cabling Telephone Converters. The first two telephone converters shown provide the required conversion allowing correct operation of the attached telephone. Each telephone port on the Phone modules acts as a Master socket, thus only Slave Telephone Converters are required. -
Page 78: Port Safety Classification
Page 78 - Port Safety Classification Port Safety Classification The Avaya IP Office systems have the following ports: • Expansion ports • 10/100 BaseT LAN ports • Telephone ports which are either DT (A-Law encoding) or DS (µ-Law encoding) • ISDN ports •... -
Page 79: Technical Specifications
Technical Data Technical Specifications General Dimensions IP401: IP403/6/12 & Exp. Modules : Width: 445mm (17.5") Height: 71mm (2.8") (unboxed) Dimensions IP401: IP403/6/12 & Exp. Modules : Width: 445mm (17.5") Height: 71mm (2.8") (boxed) Environmental 0 to +40°C. 95% relative humidity, non-condensing. Weight (unboxed) 401 403 406 412 Weight (boxed) -
Page 80: Protocols
Page 80 - Technical Specifications Protocols Protocol A-Law - - - µ-Law - - - V.120 - - - V.110 - - - RFC 1661 RFC 1570 RFC 1990 RFC 1334 CHAP RFC 1994 RFC 1962 STAC RFC 1974 MPPC RFC 2118 BACP RFC 2125... - Page 81 Technical Data Technical Specifications - Page 81 IP Office Installation Manual Technical Data - Page 81 40DHB0002USCL – Issue 9 (28th October 2003) Technical Specifications...
-
Page 82: Snmp Functionality
- Traps supported: warmStart, coldStart, linkDown, LinkUp and authenticationFailure • IETF RFC2737 ENTITY-MIB - Provides architectural representation - Groups supported: entityPhysical and entityGeneral • Avaya IPO-PROD-MIB - Provides device/entity identification OIDs • Avaya IPO-MIB - Provides root OIDs for functional MIBs - Provides system wide notifications for events relating to functional entities. -
Page 83: Trap Generation
Technical Data Trap Generation RFC1215 Generic SNMP Traps: Trap type warmStart coldStart linkDown linkUp authenticationFailure IPO-MIB: Trap type ipoGenLKSCommsFailureEvent ipoGenLKSCommsOperationalEven IPO-PHONES-MIB: Trap type ipoPhonesChangeEvent MIB Loading In order to SNMP manage an IP Office system, that is browse its MIBs and fully interpret the traps it sends out, the MIBs supported by IP Office must be loaded and compiled for use with your Network Management System. -
Page 84: Castlerock Snmpc 5.1.6C And Earlier
Page 84 - Technical Specifications CastleRock SNMPc 5.1.6c and earlier: For MIBs to be used with SNMPc they must first be copied into its mibfiles directory, which is normally C:\Program Files\SNMPc Network Manager\mibfiles. MIBs are installed by selecting Config and MIB Database from the SNMPc menu and then using the Add option and selecting the MIB file from the list presented to load and compile it. -
Page 85: Index
Index Analog 4... 10 , 14 , 18 Analogue Ports... 7 , 11 , 18 Barrier boxes IROB ... 36 BRI ... 10 , 12 , 14 , 16 , 18 , 25 , 29 , 31 , 39 , 40 , 61 , 63 , 69 , 78 , 79 Cable ties ... - Page 86 Avaya Inc. All other trademarks are the property of their respective owners. This document contains propriety information of Avaya and is not to be disclosed or used except in accordance with applicable agreements. Any comments or suggestions regarding this document should be sent to "wgctechpubs@avaya.com".
