ESCIU Ports (990-72020-04 System Only)

Connector Type:
Connector Label:
Wire-Wrap:
BNC:
Connector Location: Connector panel output module
Electrical Interface: E1 (ITU G.703 andG.704)
Ports::
Maximum cable length:150 m (either direction, to or from DDF)
CSU Functionality: None
Output During LOS Alarm:AIS
Input jitter tolerance:ITU G.823 (1993) requirements
Input wander tolerance:
097-72020-01 Revision K – December 2005
75 Ω BNC
120 Ω Wire-wrap
SPAN 1RTN1 (T, R, S) (2 sets of pins)
IN (T, R, S)
OUT (T, R, S)
SPAN 2RTN2 (T, R, S) (2 sets of pins)
IN (T, R, S)
OUT (T, R, S)
SPAN 1RTN 1 OUT
RTN 1 IN
OUT
IN
SPAN 2RTN 2 OUT
RTN 2 IN
OUT
IN
Two bidirectional:
(E1 signals are buffered and retimed in forward
direction, passed through in reverse direction)
LOS
125 μs
±
Chapter 6 Specifications
ESCIU Ports (990-72020-04 System Only)
TimeSource 3100 User's Guide 191
