Figure 3-27. The Set the Alarm Parameters Screen
The Load and Save buttons allow a file to be generated that saves the alarm
parameters in a file called TS3Kconf.sym as default. The file name for a
configuration can be saved by selecting the Save button and providing a file
name. The Load button allows the user to load a saved file that will automatically
configure the Alarm Parameters screen.
This screen allows the parameters for GPS and Holdover alarm conditions to be
modified. If you do not want to modify any of the alarm parameters, click Next>>
and continue with Step 21. Otherwise, continue with the next step.
14.Choose the alarm parameters as desired.
Table 3-8. Alarm Parameters
Setting
Severity 1
Service Affecting 1
Time to Severity 2
097-72020-01 Revision K – December 2005
The initial severity of the alarm.
The initial service affecting status of the alarm condition.
If the Escalate Alarm check-box is selected, the alarm will be escalated
to the severity and service affecting status selected under Severity 2
and Service Affecting 2, after the time period selected under Hours and
Mins has been reached. If the Escalate Alarm check-box is not
selected, the alarm will not be escalated.
Chapter 3 Installing the TimeSource 3100
Table 3-8 describes each setting.
Description
TimeSource 3100 User's Guide
Installing TimeWizard
87
