OPT-a ALMOUT=b
(990-72020-0
6 systems
only)
FRAMING=b
TS3100 DCDPASSTHRU
DCDUSERPORT=
x (See Note 9)
Notes:
1. This parameter affects all Ethernet ports. Close the Ethernet ports and log off all
users before issuing a command with this parameter.
2. Port 5550 makes a connection to this element manager to send TL1 autonomous
messages, and closes the connection when the transmission is complete.
3. Port 5551 accepts a connection from this element manager for TL1 commands
and responses.
097-72020-01 Revision K – December 2005
b = AIS Output is AIS during alarm
b = Output is squelched during alarm
SQUELCH
b = SSM Outputs are at "STU" quality level for ESF
framing and at "SSUT" level for CAS4 and
CCS4 framing during holdover alarm (SSM
requires CAS4, CCS4, or ESF framing)
b=CAS Output framing is CAS
b=CAS4 Output framing is CAS4
b=CCS Output framing is CCS
b=CCS4 Output framing is CCS4
b=ESF Output framing is ESF
b=NONE Output framing is NONE (analog) (If
ALMOUT is SQUELCH, then signal turns off
during Holdover alarm. Any other ALMOUT
option does not affect output during alarm)
INH DCD port communication is inhibited
ALW1 COM1 is the DCD interface port
ALW2 COM2 is the DCD interface port
x = 1 COM1
x = 2 COM2
x = 3 or COM3 or IP port 5001 to 5004
5001, 5002,
5003, 5004
Chapter 4 TL1 Reference
Commands
