Chapter 6 Specifications

Office Alarms

Office Alarms

Connector Panel Contacts

Connection:
Type:
Contact Rating:
Severity:
State:
Style:

Front Panel Lamps

Label:
990-72020-04 System only:Retimed spans: A, B, BYP
Type:

Front Panel Control

Label:
Type:
Function:
192 TimeSource 3100 User's Guide
Wire-wrap pins
Dry contact
1 A @ 30 V dc
0.5 A @ 60 V dc
0.5 A @ 125 V ac
Critical
Major
Minor
Normally open and normally closed
Audible and visible
Alarms (CRIT, MAJ, MIN, ACO)
Status (GPS, SYS)
Span (A, B)
Remote Oscillator (A, B)
Light emitting diode
ACO
Push button switch
Alarm cutoff (deactivates audible office alarms)
097-72020-01 Revision K – December 2005
