Allied Telesis CentreCOM FS980M/9 Command Reference Manual page 1608

LLDP C
OMMANDS
SHOW LLDP INTERFACE
Table 4: Parameters in the output of the show lldp interface command
Related show lldp
Commands
show running-config
613-50157-01 Rev C
Parameter
Port
Rx
Tx
Notif
Management Addr
Base TLVs Enabled
for Tx
802.1 TLVs
Enabled for Tx
802.3 TLVs
Enabled for Tx
MED TLVs Enabled
for Tx
lldp
Command Reference for FS980M Series
AlliedWare Plus™ Operating System - Version 5.4.7-0.x
Description
Port name.
Whether reception of LLDP advertisements is enabled on
the port.
Whether transmission of LLDP advertisements is enabled
on the port.
Whether sending SNMP notification for LLDP is enabled on
the port:
• RM = Remote Tables Change Notification
• TP = LLDP-MED Topology Change Notification
Management address advertised to neighbors.
List of optional Base TLVs enabled for transmission:
• Pd = Port Description
• Sn =System Name
• Sd = System Description
• Sc =System Capabilities
• Ma = Management Address
List of optional 802.1 TLVs enabled for transmission:
• Pv = Port VLAN ID
• Pp = Port And Protocol VLAN ID
• Vn = VLAN Name
• Pi =Protocol Identity
List of optional 802.3 TLVs enabled for transmission:
• Mp = MAC/PHY Configuration/Status
• Po = Power Via MDI (PoE)
• La = Link Aggregation
• Mf = Maximum Frame Size
List of optional LLDP-MED TLVs enabled for transmission:
• Mc = LLDP-MED Capabilities
• Np = Network Policy
• Lo = Location Information,
• Pe = Extended Power-Via-MDI
• In = Inventory
1608
