Hardware Maintenance
4−12
Retaining screws (6)
Retaining screws (3)
Figure 4−10: Retaining screw locations for GbE interface board
10. Lift the interface board clear of the instrument and place the board on a
static-free surface.
CAUTION. To prevent static damage to the removed board, be sure to store the
board in static-free packaging. Failure to properly store the board may result in
the board needing repair before it will operate properly when reinstalled.
MTM400 MPEG Transport Stream Monitor Technical Reference
