Test Parameters - Event Identity to Test Name
12819 (Hex: 0x3213)
A/65 RRT (Timer)
Description:
Applicable Standards:
12848 (Hex: 0x3230)
MGT/EIT-k presence
Description:
Applicable Standards:
13088 (Hex: 0x3320)
A/53 Prog P'digm
Description:
Applicable Standards:
13104 (Hex: 0x3330)
PAT/PMT Consistency
Description:
Applicable Standards:
13105 (Hex: 0x3331)
PAT/SDT Consistency
Description:
Applicable Standards:
13106 (Hex: 0x3332)
PAT/VCT consistency
Description:
Applicable Standards:
13107 (Hex: 0x3333)
3.6c EIT PF
Description:
Applicable Standards:
2−64
RRT Timer Error
ATSC
Passes if the current version of the MGT contains entries for
table_types EIT-0, EIT-1, EIT-2 and EIT-3 or if the MGT contains no
table_type entry for TVCT.
ATSC
A/53 Program Paradigm
ATSC
Passes if, for all programs listed in the PAT, there is a PMT on the
correct program_map_PID whose program_number matches that in the
PAT.
MPEG, DVB, ATSC, ISDB, Chinese, DCII
Passes if, for all programs listed in the PAT, there is an entry in the
SDT actual_transport_stream subtable whose service_id matches the
program_number in the PAT and whose transport_stream_id matches
the PAT.
DVB, Chinese
Passes if, for all programs listed in the PAT, there is an entry in the
VCT whose program_number matches that in the PAT and whose
channel_TSID matches the PAT.
ATSC
If either section ('0' or '1') of each EIT P/F subtable is present both
must exist. Otherwise EIT_PF_error should be indicated.
DVB, ISDB, Chinese
MTM400 MPEG Transport Stream Monitor Technical Reference
