Page 1: Installation Manual
BRIVO ACS6000 INSTALLATION MANUAL 8/15/2017... - Page 2 Level I ACS6008 Parts and Service The ACS6000 control panel contains no user serviceable parts. The lithium battery is not serviceable and is to be replaced by qualified service technicians only. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 3 Brivo Systems LLC. The information contained within this document or within the product itself is considered the exclusive property of Brivo Systems LLC. All information in this document or within the hardware and software product themselves is protected by the copyright and/or other intellectual property laws of the United States.
-
Page 4: Table Of Contents
Brivo ACS6000 Installation Manual Table of Contents INTRODUCTION ................................5 PRE-INSTALLATION PROCEDURES..........................7 GENERAL ASSEMBLY PROCEDURES ..........................13 INSTALLATION PROCEDURES ............................22 POWERING AND TESTING PROCEDURES ........................37 CONFIGURATION PROCEDURES........................... 39 © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual... -
Page 5: Introduction
ACS6000 Control Panel at client sites. This version of the manual is also intended for IT personnel, who should use it in conjunction with the Brivo Panel Networking Admin Interface Guide. It may be used by dealers and their sales professionals to help them conduct pre-sales, and to provide client support during the installation process. - Page 6 Installation Worksheet: Input Output Board • Brivo Onair Quick Start Guide • Brivo Cellular Network Router Configuration Guide • Brivo Onsite Server Quick Start Guide Technical Support: 1-866-BRIVO-4-U • www.brivo.com • © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
-
Page 7: Pre-Installation Procedures
Brivo ACS6000 Installation Manual Pre-Installation Procedures Before you begin installing the Brivo control panel, perform the following tasks to ensure a safe, speedy, and successful installation. Understand the function of the Brivo ACS6000 control panel. The ACS6000-E and ACS6000-A are four (4) reader control panels with multiple access points (up to four readers per chassis). - Page 8 Brivo ACS6000 Installation Manual installer may either contact Brivo Technical Support for assistance or simply register the panel directly. 4. Verify that the Master Administrator and any other employee who will be accessing the system have Internet access on a computer equipped with a supported Web browser.
- Page 9 Brivo ACS6000 Installation Manual 2. If additional DOOR BOARDs have been ordered with the control panel, locate and check the contents of each 2-Door Board (B-ACS6000-DB) Kit. There may be up to 15 of these kits, and each should contain the following parts:...
- Page 10 The control chassis contains the MAIN BOARD, which also serves as a 2-door board, and may also contain either a DOOR BOARD or an INPUT OUTPUT BOARD. Each standard expansion chassis (ACS6000) may contain up to two boards, in any combination of DOOR BOARDs and/or INPUT OUTPUT BOARDs.
- Page 11 Maximum Distance Calculations Calculate the distance between each chassis and its associated keypad or reader. The ACS6000 does not specify a maximum distance between the chassis and a keypad or reader, but the keypad/reader manufacturer does. Follow manufacturer guidelines for each keypad and reader.
- Page 12 UPS (Uninterruptible Power Supply) between the AC Mains and the transformer. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
-
Page 13: General Assembly Procedures
Make sure the chassis door can swing open freely to allow for access after the installation is complete. In tight spaces, the removable hinge design of the ACS6000/ACS6008 enclosures allow an installer to completely remove the chassis door and replace it just as easily upon completion of the installation. - Page 14 7. OPTIONAL: Install the physical tamper switch in the chassis. Install the tamper switch in the chassis by removing the hex collar, seating the switch inside the provided mounting bracket, and reattaching and tightening the hex collar. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 15 Brivo ACS6000 Installation Manual Switch SW 7 setting description Figure 1 - ACS6000 SW 7 Switch Bank Location Figure 2 - ACS6000 SW 7 Switch Settings © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 16 At this point, the factory reset is complete the system will now run with factory default firmware. SW 7-7 SW 7-8 Wi-Fi Enabled: Wi-Fi can be used if configured. Disabled: Wi-Fi cannot be used at all, even if configured. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 17 Ground, Power Detection, and Earth Ground to each board from the power supply. WARNING: Power Supply DO NOT USE ANY POWER SUPPLY OTHER THAN THOSE SUPPLIED WITH YOUR BRIVO PRODUCT. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 18 Figure 5 - Tamper Switch and Optical Tamper Sensor Locations NOTE: If the technician is installing the ACS6000 MAIN BOARD as a retrofit in an ACS5000 enclosure, there is no optical reflector present. The optical tamper will not function.
- Page 19 Connect the battery leads to the power supply WARNING: Backup Battery DO NOT CONNECT THE BACK-UP BATTERY AT THIS TIME. Premature connection of the battery terminals may cause damage to the control panel. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 20 Make sure the battery wires are segregated at least ¼ inch away from all other input/output wiring. NOTE: Power Standby Level 1 for UL listed systems. Figure 8 - Connect Battery Leads to Power Supply © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 21 0.49A/1.0A and not directly to any Brivo ACS6000-A/ACS6008-A Input PCBs inside of the Brivo ACS6000-E/ACS6008-E chassis) 19VDC (Secondary) 1.89A (DC) 16VAC (Secondary) 2.25 A (RMS) © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
-
Page 22: Installation Procedures
Establish CAN BUS Wiring 1. If there is an expansion board in the control chassis, connect it to the MAIN BOARD. Figure 10 - Connect Expansion Board to MAIN BOARD © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual... - Page 23 • Wire E3 to E2 in Expansion Chassis 1. • Wire E2 in Expansion Chassis 1 to E1 in the Control Chassis. • Wire E1 to the MAIN BOARD. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 24 9. Connect the CAN NODE ADDRESS jumpers. The silkscreen next to the CAN NODE ADDRESS pins shows how to position the jumpers for first four addresses. 10. Positions for additional address values are shown in the diagram below. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 25 1 is the MAIN BOARD. Record all addresses on the Installation Worksheet. These jumper settings will map to board numbers when the control panel is configured via the application. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 26 NOTE: Doors can be wired to the MAIN BOARD or to expansion boards, including both DOOR BOARDs and INPUT OUTPUT BOARDS. Figure 14 - Wire Doors for Wiegand Readers NOTE: ACS6000 Output Ratings for the ACS6000 Main Board • Two (2) reader ports, 12V, 350mA each •...
- Page 27 Brivo ACS6000 Installation Manual NOTE: ACS6000 Output Ratings for the Door Board • Two (2) reader ports, 12V, 300mA COMBINED for both readers. • Six (6) relays on the Door Board. The ratings are 24VDC, 3A each. 1. Wire the REX & DOOR terminal block.
- Page 28 1, put the FDX/HDX Door 1 switch in the FDX position. For Door 2, put the FDX/HDX Door 2 switch into the FDX position. To activate Half Duplex functionality on the ACS6000 MAIN BOARD for Door 1, put the FDX/HDX Door 1 switch in the HDX position. For Door 2, put the FDX/HDX Door 2 switch in the HDX position.
- Page 29 Enabled position. To enable RS-485 termination for Door 2, put the RS-485 termination switch in the Enabled position. Figure 17 - RS-485 Termination Switch Locations for Doors 1 and 2 © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 30 To enable dry mode for Door 2, put the Door 2 Wet/Dry Select Switch in the Dry position. Figure 18 - ACS6000 Wet/Dry Door Contact Switches for Doors 1 and 2 NOTE: Refer to the Reader/Keypad Wiring Guide for Brivo approved devices and connection diagrams.
- Page 31 Connect the orange reader wire to the TXD+ terminal. This is the standard TXD+ circuit for OSDP readers using RS-485. • Connect the brown reader wire to the TXD- terminal. This is the standard TXD- circuit for OSDP readers using RS-485. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 32 Use the wire recommended by the manufacturer of the electric strike or latch. If no wire is recommended, use a minimum of 18 AWG wire with sufficient strands for the specific electronic strike or latch. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
- Page 33 1 from the switch, while the other end is connected to the wire leading to the ACS6000 control board. e) The other wire from the ACS6000 is connected to wire 2 from the switch, as shown in Figure 21.
- Page 34 DO NOT POWER ELECTRONIC STRIKES AND LATCHES WITH THE BATTERY (OR OTHER POWER SOURCE) USED TO POWER THE CONTROL PANEL; DOING SO WILL CAUSE DAMAGE TO THE BRIVO CONTROL PANEL. USE ONLY A UL LISTED BURGLAR ALARM OR ACCESS CONTROL SYSTEM TO POWER ELECTRONIC STRIKES AND LATCHES.
- Page 35 NOTE: Wi-Fi Frequency Wi-Fi on the ACS6000 panel operates in the 2.4GHz frequency bands. 1. If you are using the Wi-Fi functionality of the ACS6000 board, please make certain that your SW 7-8 Wi-Fi switch is set to the Enabled position.
- Page 36 Brivo ACS6000 Installation Manual Figure 24 - ACS6000 Wi-Fi Integrated Circuit Location 6. When snapped into place, you may feel and hear an audible click. Ground the control chassis. 1. Wire the incoming Earth ground able to the control chassis Earth ground screw located at the bottom of the chassis.
-
Page 37: Powering And Testing Procedures
HRTBT (main heartbeat) have come on and are blinking. The local heartbeat should begin blinking immediately. • • The main heartbeat can take 30-60 seconds to establish a steady beat. Figure 25 - MAIN BOARD Heartbeats © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual... - Page 38 NOTE: A steady light is an indication of a problem, just as much as no light is. 3. If ALL power indicators are correct, attach the back-up battery and check that ALL indicators remain the same. © 2017 Brivo Systems LLC. All rights reserved. P-MAN-PUB-ACS6000 Installation Manual...
-
Page 39: Configuration Procedures
