Plan the Interface

Plan Programming

PN: 1725-36130-001_E.doc
The system administrator programs the telephone system for use with
the Wireless Telephone System using the normal administration
terminal or procedures. Programming can be done after the handsets
are registered.
Recommended programming includes assigning extension numbers
to the handsets and programming features on the telephone system so
they are easily accessible from the handsets.
For analog interfaces, macro codes are in the document relating to
configuring the system. See SpectraLink 6300 MCU: Operator's Console,
SpectraLink 6100 MCU: Installation and Operation, or SpectraLink 8000
Telephony Gateway: Administration Guide for SRP.
The following information will help the system administrator set up
the SpectraLink 8000 Wireless Telephones to operate in a way that
feels familiar and comfortable to users.
Digital Interface programming for the Wireless Telephone System will
be faster if it is planned in advance by verifying the parameters and
features on the current telephone system and wired phones. The
system administrator must assign extension numbers to the handsets
and plan the functions (trunk access, toll restrictions, system features,
ringing options etc.) to be programmed for the handsets.
One of these scenarios concerning how the handsets are programmed
should apply to this site:
• All handsets are programmed alike: All handsets will be
programmed exactly the same. Depending on the capabilities of
the switch, the system administrator can often program one
handset and use it as a model for all other handsets.
• Groups of handsets are programmed alike: Handsets are grouped
into classes that are programmed alike. Depending on the
capabilities of the switch, the system administrator can program
