Set the Switch Interface Type
PN: 1725-36130-001_E.doc
See the documentation for your SpectraLink components for more
information about wiring the demarc block or patch panel.
The following table shows the patch cord pinout for the Avaya side of
the modular 8-pin (RJ45) connector.
Pin Function
1 Receive
2 Receive
3 Transmit
6 Transmit
Each digital pair is polarity insensitive. If you reverse polarity the
system will still work.
SpectraLink 6100 MCU
The SpectraLink 6100 Master Control Unit (MCU) requires the switch
interface type to be configured using the front panel buttons. The
configuration procedures are detailed in the SpectraLink 6100 MCU:
Installation and Operation document.
SpectraLink 6300 MCU
When configuring the SpectraLink 6300 MCU, the PBX interfaces are
available as sub-menu selections when defining the Interface Module
type using the SpectraLink 6300 MCU Operator's Console. Refer to
the SpectraLink 6300 MCU: Operator's Console document for details on
configuring the Interface Modules.
SpectraLink 8000 Telephony Gateways
Connect to the SpectraLink 8000 Telephony Gateway using the serial
or modem interface. From the Main Menu, choose Gateway
Configuration. Scroll to Telephone Switch Type and press enter to
change this field, from the Submenu of PBX types, select DEFINITY.
Refer to the SpectraLink 8000 Telephony Gateway: Administration Guide
for SRP document for details on configuring the Telephone Switch
Type.
