input and output audio channels.
LED Indicators Power: Power over Ethernet (PoE) present
Note: Note: Use a PoE injector if your network switch does not supply PoE.
Network: Network connection active
Network Audio: Dante audio present on the network
Note: Error details are available in the event log in the web application.
Network Audio LED Behavior
LED Status
Off
Green
Red
Encryption:
LED Status
Off
Green
Red
Dante Network Connects to a network switch to receive Dante audio, Power over
Port Ethernet (PoE), and data from the control software.
Reset Button Resets the device settings back to the factory default
Power Over Ethernet (PoE)
This device requires PoE to operate. It is compatible with both Class 0 and Class 3 PoE
sources.
Power over Ethernet is delivered in one of the following ways:
A network switch that provides PoE
A PoE injector device
Reset
The reset button is located inside a small hole in the rear panel. Use a paperclip or other
Activity
No active signal
Device is operating
successfully
Error has occurred. See
event log for details.
Activity
Audio not encrypted
Successful encrypted audio
connection with another device
Encryption error. Possible
causes:
Encryption is enabled on
one device and not on
another
Passphrase mismatch
