< REP USB_CONNECT OFF >
< REP USB_CONNECT ERROR >
Get Matrix Mixer Routing
Command String:
< GET xx MATRIX_MXR_ROUTE yy >
ANIUSB Response:
< REP xx MATRIX_MXR_ROUTE yy ON >
< REP xx MATRIX_MXR_ROUTE yy OFF >
Set Matrix Mixer Routing
Command String:
< SET xx MATRIX_MXR_ROUTE yy ON >
< SET xx MATRIX_MXR_ROUTE yy OFF >
ANIUSB Response:
< REP xx MATRIX_MXR_ROUTE yy ON >
< REP xx MATRIX_MXR_ROUTE yy OFF >
Get Matrix Mixer Gain
Command String:
< GET xx MATRIX_MXR_GAIN yy >
ANIUSB Response:
< REP xx MATRIX_MXR_GAIN yy zzzz
>
Set Matrix Mixer Gain
Command String:
< SET xx MATRIX_MXR_GAIN yy zzzz >
ANIUSB Response:
< REP xx MATRIX_MXR_GAIN yy zzzz
>
Increment Matrix Mixer Gain
Command String:
< SET xx MATRIX_MXR_GAIN yy INC nn
>
Where xx is input channel numbers 00-06.
Where yy is output channel numbers 00 or
07-10.
The ANIUSB will respond with one of these
strings.
Where xx is input channel numbers 00-06.
Where yy is output channel numbers 00 or
07-10. Send one of these commands to the
ANIUSB.
The ANIUSB will respond with one of these
strings.
Where xx is input channel numbers 00-06.
Where yy is output channel numbers 00 or
07-10.
Where zzzz takes on the ASCII values of
0000 to 1400. zzzz is in steps of one-
tenth of a dB.
Where xx is input channel numbers 00-06.
Where yy is output channel numbers 00 or
07-10. Where zzzz takes on the ASCII
values of 0000 to 1400. zzzz is in steps of
one-tenth of a dB.
Where xx is input channel numbers 00-06.
Where yy is output channel numbers 00 or
07-10. Where nn is in steps of one-tenth of
a dB.
