Command String:
< GET DEVICE_AUDIO_MUTE >
ANIUSB Response:
< REP DEVICE_AUDIO_MUTE ON >
< REP DEVICE_AUDIO_MUTE OFF >
Set Device Audio Mute
Command String:
< SET DEVICE_AUDIO_MUTE ON >
< SET DEVICE_AUDIO_MUTE OFF >
< SET DEVICE_AUDIO_MUTE TOGGLE >
ANIUSB Response:
< REP DEVICE_AUDIO_MUTE ON >
< REP DEVICE_AUDIO_MUTE OFF >
Get Analog Output Gain Switch
Command String:
< GET xx AUDIO_OUT_LVL_SWITCH >
ANIUSB Response:
< REP xx AUDIO_OUT_LVL_SWITCH
LINE_LVL >
< REP xx AUDIO_OUT_LVL_SWITCH
AUX_LVL >
< REP xx AUDIO_OUT_LVL_SWITCH
MIC_LVL >
Set Analog Output Gain Switch
Command String:
< SET xx AUDIO_OUT_LVL_SWITCH
LINE_LVL >
< SET xx AUDIO_OUT_LVL_SWITCH
AUX_LVL >
< SET xx AUDIO_OUT_LVL_SWITCH
MIC_LVL >
ANIUSB Response:
< REP xx AUDIO_OUT_LVL_SWITCH
LINE_LVL >
< REP xx AUDIO_OUT_LVL_SWITCH
AUX_LVL >
< REP xx AUDIO_OUT_LVL_SWITCH
The ANIUSB will respond with one of these
strings.
Send one of these commands to the
ANIUSB.
The ANIUSB will respond with one of these
strings.
Where xx is ASCII channel number: 00, 03,
or 04.
The ANIUSB will respond with one of these
strings.
Where xx is ASCII channel number: 00 or
09. Send one of these commands to the
ANIUSB.
The ANIUSB will respond with one of these
strings.
