MIC_LVL >
Flash Lights on ANIUSB
Command String:
< SET FLASH ON >
< SET FLASH OFF >
ANIUSB Response:
< REP FLASH ON >
< REP FLASH OFF >
Turn Metering On
Command String:
< SET METER_RATE sssss >
ANIUSB Response:
< REP METER_RATE sssss >
< SAMPLE aaa bbb ccc ddd >
Stop Metering
Command String:
< SET METER_RATE 0 >
ANIUSB Response:
< REP METER_RATE 00000 >
Get LED Brightness
Command String:
< GET LED_BRIGHTNESS >
ANIUSB Response:
< REP LED_BRIGHTNESS n >
Set LED Brightness
Command String:
< SET LED_BRIGHTNESS n >
Send one of these commands to the
ANIUSB. The flash automatically turns off
after 30 seconds.
The ANIUSB will respond with one of these
strings.
Where sssss is the metering speed in
milliseconds. Setting sssss =0 turns
metering off. Minimum setting is 100
milliseconds. Metering is off by default.
Where aaa, bbb, etc is the value of the
audio level received and is 000-060.
aaa = input 1
bbb = input 2
ccc = output 1
ddd = output 2
A value of 00000 is also acceptable.
Where n can take on the following values:
0 = LED disabled
1 = LED dim
2 = LED default
Where n can take on the following values:
0 = LED disabled
1 = LED dim
2 = LED default
