ANIUSB Response:
< REP INPUT_METER_MODE PRE_FADER >
< REP INPUT_METER_MODE POST_FADER
>
Set Input Meter Display Mode
Command String:
< SET INPUT_METER_MODE PRE_FADER >
< SET INPUT_METER_MODE POST_FADER
>
ANIUSB Response:
< REP INPUT_METER_MODE PRE_FADER >
< REP INPUT_METER_MODE POST_FADER
>
Get Output Meter Display Mode
Command String:
< GET OUTPUT_METER_MODE >
ANIUSB Response:
< REP OUTPUT_METER_MODE PRE_FADER
>
< REP OUTPUT_METER_MODE
POST_FADER >
Set Output Meter Display Mode
Command String:
< SET OUTPUT_METER_MODE PRE_FADER
>
< SET OUTPUT_METER_MODE
POST_FADER >
ANIUSB Response:
< REP OUTPUT_METER_MODE PRE_FADER
>
< REP OUTPUT_METER_MODE
POST_FADER >
Get USB Connection Status
Command String:
< GET USB_CONNECT >
ANIUSB Response:
< REP USB_CONNECT ON >
The ANIUSB will respond with one of these
strings.
Send one of these commands to the
ANIUSB.
The ANIUSB will respond with one of these
strings.
The ANIUSB will respond with one of these
strings.
Send one of these commands to the
ANIUSB.
The ANIUSB will respond with one of these
strings.
The ANIUSB will respond with one of these
strings.
