Levels for analog and Dante channels are adjustable in the Input tab.
To monitor input levels before they reach the ANIUSB-MATRIX, set the metering to pre-
fader in the settings menu. When adjusting the faders, set metering to post-fader.
Dante Sources
1. Check the source level before it reaches the Network Interface:
Verify that the networked microphones or other Dante sources are operating at
nominal output levels.
Levels for Microflex Advance
application.
2. Adjust the digital gain in the Network Interface web application:
Use the faders or manually enter a gain value.
The digital gain adjusts the level of the signal before it reaches the matrix mixer.
Mix the levels as high as possible without the loudest channel reaching the peak
level (0 dB) on the meter.
Note: The matrix mixer provides crosspoint gain, to adjust separate submixes for different outputs.
Analog Sources
Before you begin, verify that levels from the analog devices with adjustable output levels
are operating at nominal levels. The fader adjusts the digital gain before the signal
reaches the matrix mixer.
1. Match the analog input level setting according to the incoming signal level:
Line (+4 dBu)
Aux (-10 dBV)
2. Use the fader (digital gain) to adjust the mix going to the USB or Dante output
channels.
Adjusting Output Levels
Tip: Set the metering to post-fader in the settings menu to adjust output levels.
Adjust faders in the Outputs section as high as necessary, but make sure to avoid clipping
(when the signal reaches 0 dBFS). Always adjust the input gain and crosspoint gain in the
matrix mixer before the output gain.
Analog output level:Select Line, Aux, or Mic level output signal to match the sensitivity of
the receiving device.
Parametric Equalizer
Maximize audio quality by adjusting the frequency response with the parametric equalizer.
Common equalizer applications:
Improve speech intelligibility
Reduce noise from HVAC systems or video projectors
Reduce room irregularities
microphones are adjustable through their web
™
