The character "x" in all of the following strings represents the channel of the ANIUSB
and can be ASCII numbers 0 through 4 as in the following table
00 All channels
01-04 Dante Inputs
05 Analog Input
06 USB Input
07-08 Dante Outputs
09 Analog Output
10 USB Output
Command Strings (Common)
Get All
Command String:
< GET xx ALL >
ANIUSB Response:
< REP ... >
Get Model Number
Command String:
< GET MODEL >
ANIUSB Response:
< REP MODEL
{ yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy }
>
Get Serial Number
Command String:
< GET SERIAL_NUM >
ANIUSB Response:
< REP SERIAL_NUM
{ yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy }
>
Get Channel Name
Command String:
< GET xx CHAN_NAME
Where xx is ASCII channel number: 00
through 10. Use this command on first
power on to update the status of all
parameters.
The ANIUSB responds with individual
Report strings for all parameters.
Where
yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy
is 32 characters of the model number. The
ANIUSB always responds with a 32
character model number.
Where
yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy
is 32 characters of the serial number. The
ANIUSB always responds with a 32
character serial number.
Where xx is ASCII channel number: 00
through 10.
