MGC+50/MGC+100 Getting Started Guide
8-2
The Resource Report dialog box opens.
The Resource Report window contains the following columns:
Table 8-1: Resource Report Columns
Column Title
Subject
Total
Bad
Active
Non Reserved
Description
Type of MCU resource. Includes the Network Resources
that are used by participants to connect to the system,
and Media Resources that are used by the system to run
different types of conferences.
Total number of resources of the same type installed on
the system.
The number of disabled or faulty resources of each type.
The number of ports currently used to run conferences for
each resource type.
The number of ports that are not reserved to be used
within the next 5 minutes for each resource type.
