Disassembly and Service Part Guide
Performance Credenza
Product Line
Performance Credenza Console
Tools Required
Phillips Head Screwdriver
Disassembly Time
Approximately 10 Minutes
BIFMA e3-2011
Credit 5.9.1, 5.9.2, 5.9.3
DSG-Perf Cred-Console
5151 West River Drive
Comstock Park, MI 49321
p 616.784.6016
f 616.784.4402
nucraft.com
877.NUCRAFT
5
Component
Item
Top
1
Side Panel
2
Drawer Box (Not Shown)
3
Drawer Front
4
5
Glide (Not Shown)
Brackets (Not Shown)
6
Hardware (Screws, Slides and Lock)
1
3
4
6
Material
MDF with Veneer
Particle Board with Veneer
Plywood
Particle Board with Veneer
Plastic with Threaded Steel Insert
Steel
Various Metals
2
