Specifying an SSH Version
The following example uses the ip ssh server version 2 command to enable SSH version 2 and the show ip ssh command to
confirm the setting.
Dell(conf)#ip ssh server version 2
Dell(conf)#do show ip ssh
SSH server
SSH server version
SSH server vrf
SSH server ciphers
ctr,aes256-ctr.
SSH server macs
sha2-256-96.
SSH server kex algorithms : diffie-hellman-group-exchange-sha1,diffie-hellman-group1-
sha1,diffie-hellman-group14-sha1.
Password Authentication
Hostbased Authentication
RSA Authentication
Vty Encryption
Dell(conf)#
To disable SSH server functions, use the no ip ssh server enable command.

Using SCP with SSH to Copy a Software Image

To use secure copy (SCP) to copy a software image through an SSH connection from one switch to another, use the following commands.
1 On Switch 1, set the SSH port number ( port 22 by default).
CONFIGURATION MODE
ip ssh server port number
2 On Switch 1, enable SSH.
CONFIGURATION MODE
copy ssh server enable
3 On Switch 2, invoke SCP.
CONFIGURATION MODE
copy scp: flash:
4 On Switch 2, in response to prompts, enter the path to the desired file and enter the port number specified in Step 1.
EXEC Privilege Mode
5 On the chassis, invoke SCP.
CONFIGURATION mode
copy scp: flash:
Example of Using SCP to Copy from an SSH Server on Another Switch
The following example shows the use of SCP and SSH to copy a software image from one switch running SSH server on UDP port 99 to
the local switch.
Other SSH related command include:
• crypto key generate : generate keys for the SSH server.
• debug ip ssh : enables collecting SSH debug information.
• ip scp topdir : identify a location for files used in secure copy transfer.
• ip ssh authentication-retries : configure the maximum number of attempts that should be used to authenticate a user.
• ip ssh connection-rate-limit : configure the maximum number of incoming SSH connections per minute.
716 Security
: enabled.
: v2.
: default.
: 3des-cbc,aes128-cbc,aes192-cbc,aes256-cbc,aes128-ctr,aes192-
: hmac-md5,hmac-md5-96,hmac-sha1,hmac-sha1-96,hmac-sha2-256,hmac-
: enabled.
: disabled.
: disabled.
HMAC Remote IP
