Product Overview

2. Product Overview
®
The Intel Server Board S5000VCL is a monolithic printed circuit boards that support the high-
density 1U server market.
2.1

Feature Set

Feature
Processors
Memory
Chipset
On-board
Connectors/Headers
Add-in PCI, PCI-X*, PCI
Express* Cards
On-board Video
On-board Hard Drive
Controller
LAN
System Fans
System Management
2
771-pin LGA sockets supporting one or two Dual-Core Intel
series and low-voltage Quad-Core
speeds of 1066 MHz or 1333 MHz.
For a complete list of supported processors, see the following link:
http://support.intel.com/support/motherboards/server/S5000VCL
Six keyed DIMM slots support fully buffered DIMM technology (FBDIMM) memory. 240-
pin DDR2-677 FBDIMMs must be used.
®
Intel 5000V Chipset family, which includes the following components:
®
Intel 5000V Memory Controller Hub
®
Intel 6321ESB I/O Controller Hub
External connections:
Stacked PS/2* ports for keyboard and mouse
Two RJ45 NIC connectors for 10/100/1000 Mb connections
Two USB 2.0 ports
Video connector
Com 1 or Serial A (DB9)
Internal connectors/headers:
One USB port header, capable of providing two USB 2.0 ports
One DH10 Serial B header
Six SATA ports or four SAS ports via the Intel
These ports support 3Gb/s and integrated SW RAID 0 or 1
One 40-pin (power + I/O) ATA/100 connector for optical drive support
SSI-compliant 24-pin control panel header
SSI-compliant 24-pin main power connector support the ATX-12 V standard on
the first 20 pins
8-pin +12 V processor power connector
One PCI super-slot that will support one 1U riser card with one PCI-X* and one PCI
Express* connectors
ATI* ES1000 video controller with 16 MB DDR SDRAM
Six 3 Gb/s SATA ports, or four SAS ports
®
Intel Embedded Server RAID Technology II with RAID levels
Two 10/100/1000 NICs supporting Intel
Two CPU 4-pin fan headers supporting two system blowers and one 3-pin fan header
supporting a system fan
®
Support for Intel System Management Software
Intel order number: D64569-007
Intel Server Board S5000VCL TPS
®
Description
®
® ®
Xeon processors 5300 series, with system bus
®
6321ESB I/O Controller Hub.
®
I/O Acceleration Technology
®
Xeon processors 5100
0, 1, 10
Revision 2.3
