ORDERING INFORMATION

BILL OF MATERIALS

Table 5.
Reference Designator
ALERT, LED_AVDD, LED_AVSS
C1, C4, C11, C26
C2, C3, C8, C21
C5, C19
C6, C9, C13, C27, C31, C35
C7, C18
C10, C20
C12, C30
C22
C25
C28
C29, C32
C33
C34
C36
D1, D2
D3
J1
J4
J5
L1
L2
L3, L4
LK2, LK7, LK8, LK14
LK_AVDD, LK_AVSS, LK_DVCC,
LK_REF, LK_VOUT+, LK_VOUT−
PVIN_3V–15V
R1, R41
R2
R3
R4
R5
R6, R8 to R16, R19
R7
R17
R20
R21
R22
R23
R24, R25
R26
R27
R28
R29
R30
R31
Description
LED, 0603, red
Capacitors, 0402, 16 V, 2.2 μF, ±10%
Capacitors, 0603, X5R, 35 V, 2.2 μF, ±10%
Capacitors, 0805, 10 μF, ±10%
Capacitors, 0603, X7R, 50 V, 0.1 μF, ±10%
Capacitors, 0603, X7R, 25 V, 1 nF, ±10%
Capacitors, 0805, 10 μF, ±10%
Capacitors, 0805, X7R, 10 V, 10 μF, ±10%
Capacitors, 0603, MLCC, X5R, 10 V, 2.2 μF
Capacitor, 1206, MLCC, X7R, 50 V, 2.2 μF,
±10%
Capacitor, 0805, MLCC, X5R, 10 V, 10 μF,
±10%
Capacitors, 0603, X5R, 6.3 V, 1 μF, ±10%
Capacitor, 0402, X7R, 25 V, 47 nF, ±10%
Capacitor, 0402, X7R, 10 V, 39 nF, ±10%
Capacitor, 0603, X7R, 50 V, 10 nF, ±10%
Schottky diodes
Schottky diode
120-way connector, 0.6 mm pitch
3-pin terminal block (5 mm pitch)
PMOD connector
Surface-mount power inductor
Surface-mount power inductor
Surface-mount power inductors
2-pin (0.1 inch pitch) headers and
shorting shunts
3-pin SIL header and shorting links
2-way terminal block + pluggable
terminal block
Resistors, 10 kΩ, 0.063 W, 1%, 0402
Resistor, 887 Ω, 0.063 W, 1%, 0402
Resistor, 82 kΩ, 0.063 W, 1%, 0402
Resistor, 5.1 kΩ, 0.063 W, 1%, 0402
Resistor, 160 kΩ, 0.063 W, 1%, 0402
Resistors, 0 Ω, 1%, 0603
Resistor, 49.9 kΩ, 0.1 W, 1%, 0402
Resistor, 1.5 kΩ, 0.0625 W, 1%, 0402
Resistor, 1 kΩ, 0.0625 W, 1%, 0402
Resistor, 680 kΩ, 0.1 W, 1%, 0402
Resistor, 6.65 Ω, 0.0625 W, 1%, 0402
Resistor, 6.98 Ω, 0.0625 W, 1%, 0402
Resistors, 100 kΩ, 0.063 W, 1%, 0603
Resistor, 47.5 kΩ, 0.063 W, 1%, 0402
Resistor, 4.87 kΩ, 0.063 W, 1%, 0402
Resistor, 5.9 kΩ, 0.063 W, 1%, 0402
Resistor, 15.4 kΩ, 0.063 W, 1%, 0402
Resistor, 86.6 kΩ, 0.063 W, 1%, 0402
Resistor, 1.87 kΩ, 0.063 W, 1%, 0402
Rev. 0 | Page 16 of 17
EVAL-AD5761RSDZ
Part Number Stock Code
LSQ976-Z FEC 1226390
GRM155R61C225KE44 490-10455-1-ND
GRM155R6YA225KE11 490-10733-1-ND
GRM21BR6YA106KE43 490-10514-2-ND
GRM188R71H104KA93D FEC 8820023
MC0402B102K250CT FEC 2408538
GRM188R61C106KAAL 490-10728-2-ND
GRM21BR71A106KE51L FEC 1828828
MC0603X225K100CT FEC 2310406
GRM31CR71H225KA88L FEC 1797017
GRM21BR61A106KE19L FEC 2368965
GRM188R60J105KA01D FEC 9527699
GRM155R71E473KA88D FEC 1828868
0402ZC393KAT2A FEC 2332547
GRM188R71H103KA01D FEC 2462748
NSR0240HT1G Digi-Key NSR0240HT1GOSCT-ND
BAT750-7-F FEC 1773479
FX8-120S-SV(21) FEC 1324660
CTB5000/3 FEC 151790
M20-9980646 FEC 1022238
PFL1609-222MEU FEC 2288737
PFL1609-102MEW FEC 2288736
PFL2015-682MEB FEC 2288749
M20-9990246 FEC 1022247 & 150-411
M20-9990345 & M7567- FEC 1022248 & 150410
05
1803277 + 1827127 FEC 3704725 + FEC 3704993
MC00625W0402110K FEC 1358069
CRCW0402887RFKED FEC 1692516
MC00625W0402182K FEC 1358094
MC00625W040215K1 FEC 1358061
MC00625W04021160K FEC 1358101
MC0063W06030R FEC 9331662
ERJ2RKF4992X FEC 2059172
RC0402FR-071K5L FEC 2413613
RC0402FR-071KL FEC 9239235
ERJ2RKF6800X FEC 2302619
CRCW04026R65FKED Digi-Key 541-6.65LLCT-ND
CRCW04026R98FKED Digi-Key 541-6.98LLCT-ND
MC0063W06031100K FEC 9330402
MC00625W0402147K5 FEC 2141460
MC00625W040214K87 FEC 1803106
MC00625W040215K9 FEC 1803114
MC00625W0402115K4 FEC 1803152
MC00625W0402186K6 FEC 1803744
MC00625W040211K87 FEC 1803063
