C H
ONFIGURE UMMINBIRD
The instructions in this section apply to the following Humminbird radar models only:
• RH 5
• RH 44
• AS 21RD4KW
• AS 12RD2KW
NOTE: The instructions in this section do not apply to the Humminbird CHIRP radar.
Radar Configuration
The radar should be configured by a qualified radar technician after installation or equipment repair. The settings in this section
should only be needed periodically. We recommend that you contact Humminbird Customer Service at 1-800-633-1468 before
using the menus in this section.
WARNING! The features in this section affect the performance of the radar and should only be adjusted by a qualified radar
technician.
CAUTION! Before the radar settings are adjusted, or before the SOLIX software are updated or restored to system defaults, export
the radar installation settings. See Export Radar Installation Settings.
Open the Radar Installation Menu
1. Press the HOME key.
2. Select Settings.
3. Select Radar > Installation.
menu
options
Radar Configuration
R
ADAR
Radar Installation Menu
214
(I R O
NSTALLATION AND EPAIR NLY
preview
window
)
