The available alarms are determined by the connected equipment, so your control head may provide more or less options than the
information shown here.
System
Vessel
Navigation
Sonar
Radar
Temperature
Engine
Change System Settings
Your control head was configured during the installation setup. To change the system settings such as the backlight, key sounds,
units of measurement, and the time and date format, select Settings from the Home screen. See Manage your Control Head for
more information.
1. Press the HOME key.
2. Select Settings.
3. Select General.
NOTE: To reconfigure the control head with the Setup Guide, select the Setup Guide tool from the Home screen.
Start Standby Mode
To conserve power while the control head is not in-use, start Standby mode.
1. Press the POWER key.
2. Select Standby.
3. Press the RIGHT Cursor key.
4. Turn off Standby Mode: Press the POWER key.
Power Off
Many of the control head settings can be accessed quickly from the Power X-Press Menu. You can also turn off Radar transmission
and change the transducer source from this menu.
Power Off
1. Tap the top, right corner of the status bar.
OR
Press the POWER key.
2. Select Power Off.
Additional Keypad Option
Press and hold the POWER key.
Voltage, Lost Heading (compass/heading sensor required), etc.
Drift Limit, SOG (Speed over Ground), STW (Speed through Water), etc. Also, see Views:
Understand the Data Box Digital Readouts for more information.
See Chart Overview: Navigation Alarms Overview for details.
See Sonar Overview: Sonar Alarms for details.
See Radar Overview: Radar Alarms for details.
Temp (High) or Temp (Low). To change the Temperature sources, see Installation Information:
Set up your Humminbird Network.
Low Fuel, Engine Temp, Oil Level, Coolant Level, Check Engine, etc. To change Engine and Fuel
sources, see Installation Information: Set up a NMEA 2000 Network.
13
