Display The Autochart Live Map - Humminbird SOLIX Operation Manual

D A
ISPLAY THE UTO
You can make changes to the AutoChart Live map during recording or after you've saved your map. You can also view bottom
hardness or vegetation data, and you can customize how the data is displayed.
Display/Hide your Custom Map
The custom map can be displayed or hidden while you are recording or after the map is saved. You can also adjust the transparency.
Display the Map
1. With a Chart View displayed on-screen, tap Chart in the status bar, or press the MENU key once.
2. Select AutoChart LIVE.
3. Select AutoChart LIVE. Tap the check box, or press the ENTER key, to add a check mark to it.
Adjust the Transparency
1. Press and hold the AutoChart LIVE slider, or turn the Rotary dial, to adjust the transparency.
move the
slider
Hide the Map
1. With a Chart View displayed on-screen, tap Chart in the status bar, or press the MENU key once.
2. Select AutoChart LIVE.
3. Select AutoChart LIVE. Tap the check box, or press the ENTER key, to remove the check mark.
AutoChart LIVE
C L M
HART IVE AP
Adjusting the Overlay Transparency
110
