C V
USTOMIZE THE
The Bottom Layer is displayed on top of the AutoChart Live map and can be displayed as bottom hardness or vegetation. Vegetation
shows the sonar returns interpreted as vegetation on the Chart View. Both bottom hardness and bottom vegetation cannot be
displayed at the same time in Chart View.
Show/Hide Vegetation
Show Vegetation
1. From the AutoChart Live menu, select Hardness Layer or Vegetation Layer. Tap, or press the ENTER key, to add a check mark
to the box.
2. Select Vegetation.
3. Adjust the Transparency: Press and hold the slider, or press and hold the ENTER key, to adjust the setting.
Hide Vegetation
1. From the AutoChart Live menu, select Vegetation Layer. Tap, or press the ENTER key, to remove the check mark from the box.
D
EGETATION ISPLAY
Displaying the Vegetation Layer (Map Source: Humminbird)
S
ETTINGS
119 AutoChart LIVE
