Customize The Bottom Hardness Display Settings - Humminbird SOLIX Operation Manual

C B
USTOMIZE THE
The bottom layer is displayed on top of the AutoChart Live map and can be displayed as bottom hardness or vegetation. Bottom
Hardness shows strong sonar returns resulting from compacted sediment, rocks, fallen trees, etc.
Show/Hide Bottom Hardness
The bottom layer is displayed on top of the AutoChart Live map, and you can adjust the transparency to see different layers on the
view. Both bottom hardness and bottom vegetation cannot be displayed at the same time in Chart View.
Show Bottom Hardness
1. From the AutoChart Live menu, select Hardness Layer or Vegetation Layer. Tap, or press the ENTER key, to add a check mark
to the box.
2. Select Bottom Hardness.
3. Adjust the Transparency: Press and hold the slider, or press and hold the ENTER key, to adjust the setting.
Hide Bottom Hardness
1. From the AutoChart Live menu, select Hardness Layer. Tap, or press the ENTER key, to remove the check mark from the box.
AutoChart LIVE
H
OTTOM ARDNESS
Displaying the Bottom Hardness Layer (Map Source: Humminbird)
D S
ISPLAY ETTINGS
116
