Frequency, distance and time of day

The extent to which a radio wave is reflected depends on the frequency that is used. If
the frequency is too low the signal is absorbed by the ionosphere. If the frequency is too
high the signal passes straight through the ionosphere. Within the HF band, low
frequencies are generally considered to be in the range of 2 to 10 MHz. High frequencies
are above 10 MHz.
A frequency chosen for daytime transmission may not necessarily be suitable for night-
time use. During the day the layers of the ionosphere are thick. The layers absorb lower
frequencies and reflect higher frequencies. At night, the ionosphere becomes very thin.
The low frequencies that were absorbed during the day are reflected and the high
frequencies that were reflected during the day pass straight through.
Summer HF communications usually operate on higher frequencies than those used in
winter over the same distance.
Solar activity varies over an 11 year cycle. Higher frequencies need to be used during
periods of peak activity.
It is important to remember that you may need to change the frequency you are using to
achieve the best communication. The general rules of thumb for HF communication are:
•
•

Channels and modes

A channel is a name that is given to a frequency or a pair of frequencies, for example,
'Channel 1', '4500' and 'Headquarters'. The frequencies may be any frequencies within
the HF range.
Each channel has one or more modes associated with it. Each mode indicates a sideband
that can be used with the channel, such as USB or LSB. When you make a call you need
to specify the channel and the mode you want to use.
Table 3

Table 3: Examples of channels and modes

Channel
Channel 1
Headquarters
2110 SSB Transceiver Reference Manual
the higher the sun, the higher the frequency
the further the distance, the higher the frequency
shows examples of channels and the information associated with them.
Receive frequency
4500
Transmit frequency
(kHz)
10600
4500
22758
HF radio transmission
Modes
(kHz)
10600 LSB, USB
–
23000
AM
USB
