FIGURE 6
1
1
Crossbar
FIGURE 7
FIGURE 8
Step
Install the Table Bed Assembly (CP-1300) to the A-Frame (CP-1100)
IMPORTANT: The Table Bed Assembly is heavy - be sure to complete this step with two people.
• Lift the Table Bed Assembly (CP-1300) and hold in inverted position.
• Lower the Table Bed Assembly so the back of the Table Bed rests behind the Crossbar
(Figure 6), and place the shrouds on either side of the motor housing onto the top of the
A-Frame.
• Using the Allen Wrench (IA-1149), secure one Chicago Post & Bolt (CP-0038) to the side of
the shroud (Figure 7), and two Pan Head Bolts (CP-1128) to the front of the shroud (Figure 8).
Complete on both sides.
2
