Teeter Hang Ups NXT-R Owner's Manual

INVERTING
Inverting
When correctly balanced, the table will rotate in response to simple arm movements. To
invert, lift your arms overhead slowly and to return upright, bring your arms back to your
sides. Your arms provide the weight needed to rotate the table. (Figure 12).
To ensure the inversion table does not rotate too far, too quickly:
• Set the Rotation Adjustment to Setting "C" (as explained on pg. 2);
• Attach the Tether Strap to the underside of the table and test to maximum rotation;
• Raise one arm at a time, and do so very slowly (the faster you move, the faster the
inversion table will rotate).
Returning Upright
To return to the upright position, put your arms at your sides. Since your body may have
lengthened or shifted on the Table Bed during inversion, you may need to bend your
knees to shift your body weight to the foot side of the pivot point.
or try to sit up (Figure 13).
Full Inversion
Definition: Hanging completely upside down by your ankles with your back free from the
table. DO NOT attempt this step until you are comfortable with partial inversion.
!
WARNING
To reduce tipping hazard, confine all inverted activities to smooth movements.
Aggressive exercises that involve vigorous body movement can cause the table to tip
over, resulting in serious injury or death!
• Disconnect the Tether Strap.
• Set the Rotation Adjustment in the top hole setting "A" if you want the table to "lock"
firmly while inverted. If you are 220 lbs (100 kg) or more, set the Rotation Adjustment
in the "B" hole setting.
• From a balanced position on the table, slowly raise both hands over your head to begin
rotation. You may need to assist the last few degrees of rotation by pushing on the floor
or A-frame until the table pulls away from your back (Figure 14). In your correct balance
setting, your weight will keep the table "locked" in this position until you are ready to
return upright.
To Release from the Inverted "Locked" Position:
• Place one hand on the top of the Table Bed behind your head and place the other hand
on the bottom bar of the A-frame in front of you.
• Pull both hands together (Figure 15). This will rotate the table out of the "locked"
position. Slowly move your arms and elbows to your sides to complete the rotation.
USE CAUTION: Elbows protruding over the sides of the table bed could get pinched
between the A-frame and the Table Bed as you return upright (Figure 16).
It is your responsibility to familiarize yourself with the proper use of the equipment and the inherent risks of inversion, such
as falling on your head or neck, pinching, entrapment or equipment failure.
DO NOT use the inversion table until you have thoroughly and carefully read the Owner's Manual, viewed the instructional
DVD, reviewed all accompanying documents and inspected the equipment.
smooth operation prior to each use.
DO NOT lift your head
!
WARNING
ALWAYS test and inspect the equipment for
4
Fig. 12
FAILURE TO FOLLOW INSTRUCTIONS AND WARNINGS COULD RESULT IN SERIOUS INJURY OR DEATH.
WARNING - To reduce the risk of injury to persons:
Fig. 13
• Read and understand all the instructions, view the instructional video, review all other accompanying documents, and inspect the
equipment before using the inversion table. It is your responsibility to familiarize yourself with the proper use of this equipment and the
inherent risks of inversion, such as falling on your head or neck, pinching, entrapment, or equipment failure. It is the responsibility of the
owner to ensure that all users of the product are fully informed about the proper use of the equipment and all safety precautions.
• Close supervision is necessary when the inversion table is used near children, or by or near invalids or disabled persons.
• Use the inversion table only for its intended use as described in this manual.
the manufacturer.
• NEVER drop or insert any object into any opening.
• DO NOT use or store product outdoors.
• DO NOT use if you are over 6 ft 6 in (198 cm) or over 300 lbs. (136 kg). Structural failure could occur or head/neck may impact
the floor during inversion.
• DO NOT allow children to use this machine.
• Keep children, bystanders, and pets away from machine while in use.
• Keep body parts, hair, loose clothing and jewelry clear of all moving parts.
• The inversion table has no user serviceable parts.
• This product is intended for home use only.
Fig. 14
• DO NOT operate equipment while under the influence of drugs, alcohol, or medication that may cause drowsiness or disorientation.
• ALWAYS inspect the equipment prior to use. Make sure all fasteners are secure.
• ALWAYS replace defective components immediately and/or keep the equipment out of use until repair.
• ALWAYS position equipment on a level surface and away from water or ledges that could lead to accidental immersion or falls.
• ALWAYS wear securely tied lace-up shoes with a flat sole, such as a normal tennis style shoe.
interfere with securing the ankle clamps, such as shoes with thick soles, boots, high-tops or any shoe that extends above the anklebone.
• ALWAYS make sure the equipment is properly adjusted to the correct user settings prior to each use.
• DO NOT use aggressive movements, or use weights, elastic bands or any other exercise or stretching device while on the inversion table.
Fig. 15 • New users, and users who are physically or mentally compromised, will require the assistance of a partner to ensure they are able to find
the correct balance setting and can return to an upright position unassisted.
• If you feel pain or become light-headed or dizzy while inverting, immediately return to the upright position for recovery and eventual
dismount.
• DO NOT use the equipment without a licensed physician's approval. Carefully review the following list of medical contraindications for
inversion with your licensed physician: (This is not an exhaustive list, it is intended only for reference)
· Middle ear infection · Glaucoma
· Extreme obesity · Retinal detachment
Fig. 16 · Pregnancy · Conjunctivitis
· Hiatal hernia · High blood pressure
· Ventral hernia · Hypertension
• Refer to additional warning notices posted on the equipment. If a product label or Owner's Manual should become lost, damaged or
illegible, contact Customer Service for replacement.
SAVE THESE INSTRUCTIONS
OWNER'S MANUAL
NXT-R
U.S. and foreign patents apply. Other foreign patents pending.
!
WARNING
DO NOT use attachments not recommended by
DO NOT use in any commercial, rental or institutional setting.
DO NOT
· Heart or circulatory disorders · Bone weakness (osteoporosis)
· Spinal injury · Recent or unhealed fractures
· Cerebral sclerosis · Medullary pins
· Acutely swollen joints · Surgically implanted orthopedic supports
· Recent stroke or transient · Use of anticoagulants
ischemic attack (including high doses of aspirin)
USA: 1-800-847-0143, info@teeter-inversion.com
International: +1-242-362-1001, info@inversioninternational.com
©COPYRIGHT 2010; International law prohibits any copying. 0210-1 NX-1700
R
Inversion Table
TM
wear any footwear that could
Specifications subject to change without notice.
