Assembly Instructions
GET STARTED
Assemble Your
EP-560
Inversion Table
™
For gravity-assisted stretching and decompression
Follow along with these instructions
OR
Scan to download the free BILT app
and search 'Teeter' in app.
EN
* Specifications may vary from this image and are subject to change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the EP-560 and is the answer not in the manual?

Questions and answers

Related Manuals for Teeter EP-560

Summary of Contents for Teeter EP-560

  • Page 1 EP-560 Inversion Table ™ For gravity-assisted stretching and decompression Follow along with these instructions Scan to download the free BILT app and search ‘Teeter’ in app. * Specifications may vary from this image and are subject to change without notice.

  • Page 2: Table Of Contents

    If you have any questions concerning assembly or if any parts are missing, DO NOT RETURN THE ITEM TO THE STORE OR CONTACT THE RETAILER. Our dedicated product service experts can help! Contact Teeter Customer Service at 800-847-0143, or via online forms or Live Chat at teeter.com.

  • Page 3: Important Safety Instructions

    • DO NOT store the inversion table upright if children are present. Fold and lay the table on the floor. DO NOT store outdoors. • DO NOT use aggressive movements, or use weights, elastic bands, any other exercise or stretching device or non-Teeter ®...

  • Page 4: Items For Assembly

    I T E M S FO R A S S EM B LY Parts are not shown to scale. Hardware drawings located on the insert inside each Hardware Kit. ITEM NO. ITEM NAME ITEM NO. ITEM NAME Main Shaft Assembly A-Frame Base Assembly E61600B with T-Pin Ankle Lock System...

  • Page 5: Understanding Your Inversion Table

    A G U I D E TO YO U R I NVE R SI ON TA B L E Before reading further, study the drawing below to familiarize yourself with the important components of your Teeter Inversion Table. Located on back of table bed.

  • Page 6: Safety Warning Labels & Product Specifications

    This drawing indicates the locations of the warning labels found on your product. If a label is missing, illegible or is removed, contact Teeter Customer Service to request a complimentary replacement label. Note: Image and labels below not shown at actual size.

  • Page 7: Assembly Steps

    L E T ’ S GE T STA RTE D Unpack and Prepare Your Workspace • If possible, assemble the equipment at or near the space in which you intend to use it to avoid moving it later. • Unpack all parts and support materials. Set aside packing materials and clear your work area. •...
  • Page 8 S T E P 2 ASSEMBLE TABL E BED NOTE: Do not detach the Bed Frame Extension from the clips as you proceed. Bed Frame Extension Figure 4: Lay the Upper and Lower Table Bed parts face down on the floor. Lift the base of the Bed Frame Extension to fit the Lower Table Bed into the plastic track of the Upper Table Bed.
  • Page 9 A S S E M B LE RO L L E R H I NG E S S T E P 3 FIGURE 4 FIGURE 4 TO TA BL E B E D Figure 7: Familiarize yourself with the 3-Hole Roller Figure 7 Hinge and Cam Lock terms.
  • Page 10 Figure 9: For ease of assembly, rest the Table Bed against the Crossbar at the front of the A-Frame. Figure 9a: On one side of the Table Bed, lift and hold the Cam Lock up all the way to unlock. In your other hand, hold one Roller Hinge near the Pivot Pin.
  • Page 11 S T E P 4 ASSEMBLE TABL E BED TO A- F RA M E Figure 12: Face the front of the A-Frame where the Crossbar is located. Grasp both Roller Hinges, right above the Cam Lock, and lift the Table Bed. Allow the top of the Table Bed to rotate toward the floor, so that the back of the Table Bed is now facing you and the top of the Table Bed is in...
  • Page 12 S T E P 5 ASSEMBLE ANKL E CO MFO RT D IA L Figure 16: Use the Ankle Comfort Dial Hardware Kit to assemble the Ankle Comfort Dial. Slide the Ankle Comfort Dial Bar with pre- assembled Ankle Comfort Dial into the hole at the front base of the Main Shaft.
  • Page 13 S T E P 6 ASSEMB LE REAR A N KL E BA R Figure 18: With the Ergo Embrace logo facing up, insert the Rear Ankle Bar with the pre-assembled Ankle Cup into the hole at the base of the Main Shaft. Figure 18 Figure 19: Use the Rear Ankle Bar Hardware Kit to assemble the Ankle Bar.
  • Page 14 Figure 21: Fit the Rubber Plug into the open end of the Rear Ankle Bar. TIP: You may want to use a rubber mallet to assist with assembly. Figure 21 Figure 21a: Secure the Rubber Plug with the screw using the screwdriver provided. If the screw does not tighten easily, you may need to reposition the alignment of the Rubber Plug.
  • Page 15 S T E P 7 ASSEMBLE FR ONT A NK LE BA R WARNING Pull up & hold Failure to assemble the Ankle Lock System properly could result in serious injury or death! Pull Figure 22: Pull the T-shape locking pin to disengage from the Front Ankle Bar.
  • Page 16 Figure 24: Use the Front Ankle Bar Hardware Kit to finish assembling the Front Ankle Bar. Hand tighten 1 × Screw through the base of the Front Ankle Bar housing into the set screw slot. Proceed to tighten with the 5mm Allen Wrench. Figure 24 Figure 25: With the Ergo Embrace logos facing up, slide the remaining two (2) ankle cups onto...
  • Page 17 ASSEMBLE MAI N SHA F T S T E P 8 TO TABL E BED Figure 28: Stand on the LEFT side of the A-Frame, holding the Main Shaft with the height markings facing up. Begin to slide the end of the Main Shaft into the Main Shaft Housing at the base of the Table Bed.
  • Page 18 MISASSEMBLY CHECK WARNING If your Teeter Inversion Table looks like Image A or B, your inversion table has been misassembled and is unfit for use. Improper assembly could result in serious injury or death! Image B Image C Image A...
  • Page 19 AT TACH AN GLE T ETHE R S T E P 9 & HEAD PI LLOW Attach Angle Tether The tether will come pre-assembled to the A-Frame. Figure 31: Unfold the adjustable tether and clip it to the U-Bar on the underside of the Table Bed.
  • Page 20 Table Bed so it fits comfortably at the small of your back. Stabilize the inversion table to prevent rotation during assembly. Position the bridge with the Teeter logo at the base and facing towards you. Figure 33: First, insert the bottom two notches of the bridge into the desired horizontal slots on the lower portion of the Table Bed.
  • Page 21 S T E P 1 1 ATTACH ACUPRESSURE NODES (OPTIONAL) Personalize the intensity and target zone of the Acupressure Nodes by positioning the varying sizes along the bed tracks as desired. Figure 36: Determine your desired node position along the table bed. Unscrew the black backing from the node and insert the backing into the slot from the rear of the bed so the threads are visible from the front.

  • Page 22: Before Inverting

    NEXT STEP Locate User Guide and Get Started with Inversion Refer to the User Guide attached to your EP-560 Inversion Table. This is your step-by-step guide to customizing your user settings for a smooth and effortless inversion experience. Ensure User Guide Remains on Product Figure 39 &...

  • Page 23: Warranty Terms & Registration

    Under no circumstances shall Teeter, or any other party involved in the sale of this product, have any liability for incidental or consequential damage arising from breach of an express or implied warranty on any Teeter product.
  • Page 24 This page intentionally left blank.

  • Page 25: Terms & Conditions

    Teeter also offers a 30-Day Price Match Guarantee. If at any time within 30 days of placing your order, you find the same, new-condition model advertised in print or online by a Teeter authorized dealer for a lower price, send Teeter customer service a copy of the ad (dated and published within 30 days of placing your order) and they will either adjust your future payments for the new price or refund you the difference.
  • Page 26 Sites or these materials, whether or not the circumstances giving rise to such cause may have been within the control of Teeter or of any vendor providing software or services. In no event will Teeter or any such parties be liable to you, whether in contract or tort, for any direct, special, indirect, punitive, consequential or incidental damages, attorney fees, or any other damages of any kind even if Teeter or any other such party has been advised of the possibility thereof.
  • Page 28 Tel. +49 511 62628630 Teeter Decompression Devices are multiple user, reusable devices for home use, intended to provide traction to the spine while stretching the para-spinal muscles and soft tissues. The devices provide non-powered traction and are meant for use by adults.
