OM-TDB TA/2
The Groen TA/2 assembly is an electrically
powered mixer with dual counter rotating
agitators, which is incorporated into Groen
kettles of 20 or 40 quart c apacity.
The agitator frame is constructed of tubular
stainless steel and fitted with scrapers. It is
easily removed for cleaning.
WARNING
TURN OFF POWER AT THE CIRCUIT
BREAKER PRIOR TO INSTALLATION.
THE MIXER MUST BE INSTALLED BY
PERSONNEL WHO ARE QUALIFIED TO
WORK WITH ELECTRICITY. IMPROPER
INSTALLATION CAN RESULT IN INJURY
TO PERSONNEL AND/OR DAMAGE TO
EQUIPMENT.
ANY MECHANICAL
CHANGE MUST BE APPROVED BY THE
GROEN FOOD SERVICE ENGINEERING
DEPARTMENT.
Your Groen mixer has been test operated at the
factory and is furnished with all internal wiring. It
is complete and ready for final connection. A
wiring diagram is furnished at the rear of this
manual.
A. Installation is as follows:
1. Set the cooker/mixer in place and level it. If
the mixer is a tilting model, confirm that there
is enough rear or side clearance, depending
on model, and overhead clearance to tilt the
mixer safely through its entire tilting range.
Provide enough clearance to permit access
for service as well. Fasten the cooker/mixer
to the floor or deck to reduce chances that
the unit could tip over if unit is provided with
flanged feet.

Equipment Description

Installation and Start-Up

OR ELECTRICAL
6
The mixer has a variable speed drive with
electrical speed control that powers on 1/2 HP
motor.
For a description of the kettle component of
your cooker/mixer, see the separate kettle
manual.
2. Provide the proper electric power supply as
specified on the electrical information plate
attached to the mixer. Observe local codes
and/or The National Electrical Code in
accordance with ANSI/NFPA 70 - latest
edition. The installation must conform to the
code that has the more strict requirements.
3. TA/2 mixer requires a seperate 120V, 60Hz,
15 Amp outlet. Unit is provided with a 6 ft.
long cord and grounded plug.
WARNING: DO NOT cut off the ground plug.
4. Electrical service for the kettle will
require a separate connection. See
specific kettle manual.
the
WARNING
TO PREVENT POSSIBLE
SHOCK, GROUND THE UNIT AT THE
TERMINAL PROVIDED.
5. Use the following check list to confirm that
the installation is correct.
Unit level
