The Groen TDB/8-20-CFC cooker/mixer consists
of a water-jacketed kettle with a motor-driven
mixer. The 20 quart tilting kettle is equipped with
electronically controlled electric heaters for the
jacket.
The kettle of Model TDB/8-20-CFC is
constructed of stainless steel welded into one
piece. The body has a reinforced rim and a
butterfly-shaped pouring lip. It is fitted with an
integral water jacket. The kettle exterior has a
bright semi-deluxe finish. The kettle's pouring
height allows filling pans up to 4 inches high on
a table top.
The kettle's internal electric heaters provide
uniform heat in three stages, with jacket
temperature control over the range of 140 to
180ºF (60 to 80ºC).
Kettle Capacity
Diameter
Depth
Side to Side
Vertical
4 OM-TDB/8-20-CFC

Equipment Description

COOKER/MIXER CHARACTERISTICS
20 Quarts
14 inches
11 Inches
SPACE REQUIRED (Approximate)
19 inches
30 inches
In addition to the three-stage adjustable
thermostat for operating control, the unit has a
high limit thermostat, as a safety feature, plus an
indicator lamp and water gauge glass, with which
to monitor kettle operation.
Mixing is controlled with a power switch. The
switch doubles as a circuit breaker for motor
protection. The agitator continuously sweeps the
side and bottom of the kettle.
Electric power for the kettle and mixer is
supplied through a plug-in power cord, which is
furnished with the unit. Standard unit operation
requires connection to single phase, 115 VAC,
60 Hz electrical service. The unit must be
supplied from a separate, dedicated 20A branch
circuit.
The Agitator fits over the agitator
post inside the kettle.
18.8 Liters
36 cm
28 cm
48 cm
76 cm
