Note: Return to normal operation from shutdown can take about 4 seconds. Although there is
no output voltage to power PoE devices during shutdown, data signals may still be present on
the data pair lines of the CAT5e cable.
Fig. 1
Fig. 1a
www.altronix.com
NetWay1
Single Port Injector (Midspan)
24VAC/VDC, 1.2A Input
48VDC 15.4W max. per IEEE 802.3af
Equipment 92R2
Access Control PoE Injector
Attack Class
General Signaling
Fig. 2
Equipment 92R2
Fig. 2a
I.T.E. 43KC
NetWay1X
Single Port Injector (Midspan)
Input:
Output: IEEE 802.3at (30W) and
24VAC/VDC
Input
I.T.E. 43KC
24VAC/VDC
Input IN
Port Status
Non-Powered Device
0Ω < R PORT < 200Ω
Port Open R PORT > 1MΩ
Port On 25kΩ
Low Signature Resistance
300Ω < R PORT < 15kΩ
High Signature Resistance
33KΩ < R PORT < 500kΩ
Port Overload Fault
- 2 -
I
Made in U.S.A.
www.altronix.com
24VAC/VDC, 1.5A
IEEE 802.3af (15.4W)
compliant.
IN OUT
Z109
Power
OUT Shutdown
NetWay1 Port Status and LED Flash Codes
Flash Code
OFF
OFF
ON
1 Flash
2 Flashes
5 Flashes
NetWay1:
Fig. 1b
Structured
24VAC/ Cable from
24VDC Input Network
Switch
IP Camera, IP Lock or IP device,
NetWay1512 or NetWayXT
Port
Status
NetWay1X:
Power In LED
24VAC/
24VDC Input
Power
Shutdown
l l
Z
Z Z
l l
Structured Cable from
24VDC Input
Fig. 1c
Structured
Cable from
Network
Switch
Structured Cable from
IP Camera, IP Lock or IP device
Flash Pattern
LED OFF
LED OFF
LED ON
l l l
Z
l l l
Z Z
l l
Z Z Z Z Z
12VAC to 24VAC or
5VDC to 24VDC Input
for PoE shutdown
24VAC/
PoE LED
Fig. 2b
12VAC to 24VAC or
5VDC to 24VDC Input
for PoE shutdown
l l l l
Z
l l l
Z Z
l l l l
NetWay1 / NetWay1X
