- Page 1 INSTRUCTION MANUAL ® Votator SCRAPED SURFACE HEAT EXCHANGER READ AND UNDERSTAND THIS MANUAL PRIOR TO OPERATING OR SERVICING THIS PRODUCT. FORM NO.: 95-03057 REVISION: 11/2012...
- Page 2 Copyright © 2005, 2012 SPX Corporation. without notice and does not represent a commitment on the All Rights Reserved. part of SPX Corporation. No part of this manual may be reproduced or transmitted in any form or by any means, Revision Date: 11/2012...
-
Page 3: Table Of Contents
Cylinder Assembly ..................7 Product Side Pressure Rating ..............7 Jacket Pressure Rating ................7 Machine Serial Number ................7 Votator II Media Configurations ..............8 Special Considerations for Vertical Votator II ..........8 Installation ....................9 Site Selection Considerations ..............9 Foundation & Drainage ................9 Clearances ....................9 Leveling the Unit ..................9... - Page 4 Routine Maintenance Checklist - Vertical Votator II ........37 Routine Maintenance Checklist - Horizontal Votator II ........38 Scheduled Maintenance ................40 Preventive Maintenance ................41 Mutator Shaft Bearing .................41 Extra Heavy Duty Votator II Shaft Bearing ..........41 Shafts ......................42 Gear Drive ....................42 Blades ......................42 Mechanical Seals ..................42 Tubes ......................42...
- Page 5 Assembly of 2012 Primary Seal Body ............59 Assembly of Secondary Seal Body (For Double Mechanical Seal Only) ... 60 Seal Assembly Installation on Shaft ............60 Servicing Mechanical Seals - Vertical Votator II ........61 Parts Lists ....................63 Latch ......................63 Product Heads .....................63...
-
Page 6: Warranty
Warranty Waukesha Cherry-Burrell Warranty Seller warrants its products to be free from defect in materials and workmanship for a period of one (1) year from the date of shipment. This warranty shall not apply to products which require repair or replacement due to normal wear and tear or to products which are subjected to accident, misuse or improper mainte- nance. -
Page 7: Safety
READ AND UNDERSTAND THIS MANUAL PRIOR TO INSTALLING, OPERATING OR SERVICING THIS EQUIPMENT SPX recommends users of our equipment and designs follow the latest Industrial Safety Standards. At a mini- mum, these should include the industrial safety requirements established by: 1. -
Page 8: Care Of Stainless Steel
Care of Stainless Steel Waukesha Cherry-Burrell Care of Stainless Steel Stainless Steel Corrosion Corrosion resistance is greatest when a layer of oxide film is formed on the surface of stainless steel. If film is disturbed or destroyed, stainless steel becomes much less resistant to corrosion and may rust, pit or crack. -
Page 9: Introduction
400 psi (28 bar) @ 400°F (204°C) - Oval Tube Rating • 600 psi (42 bar) @ 400°F (204°C) - Std. Votator II • 800 psi (56 bar) @ 400°F (204°C) - U Stamp Votator II Jacket Pressure Rating • 250 psi (17.5 bar) @ 400°F (204°C) •... -
Page 10: Votator Ii Media Configurations
• VAPOR For steam or refrigeration. Special Considerations for The Vertical Votator II cylinder assembly is shipped for on-site installation on the mounting pole. When receiving the shipment, Vertical Votator II check for the following or multiples of (depending on the order) shipped separately in their own crate or crates: •... -
Page 11: Installation
Licensed Electrician in accordance with local regulations. Std. Votator II accepts 7-1/2 HP (5.5 kW), 10 HP (7.5 kW), 15 HP (11kw) or 20 HP (15 kW); Extra Heavy Duty Votator II accepts 25 HP (18.8 kW), 30 HP (22.5 kW) or 40 HP (30 kW). -
Page 12: Mutator Rotation Check
Have a Licensed Electrician change the wiring so the rotation of the shaft is correct. Mechanical Seals The Votator II is furnished with either a single or double mechanical seal on both ends of the mutator shaft. Units furnished before 2005 were installed with either a single or double mechanical seal configuration. -
Page 13: 2005 Mechanical Seal Design
Waukesha Cherry-Burrell Installation 2005 Mechanical Seal Design Units furnished between 2005 and 2012 have a one-piece chrome-oxide coated rotating body running against a stationary ceramic head insert. It can easily be converted to a double mechanical seal by adding secondary components to contain a steam or water flush. -
Page 14: Flush Fluid Requirements
• Install a safety valve to protect jacket. downstream of the Votator II unit. • Provide temperature indicators on both sides of Votator II WARNING: Do not allow a unit. volume of liquid to become • Provide pressure gauge on discharge side of pump. -
Page 15: Suggested Media Piping For Water Or Liquid
Waukesha Cherry-Burrell Installation Table 1: Call Outs For Figure 8 1. Steam IN 2. Strainer 3. By-Pass Line 4. Steam Pressure Regulator 5. Steam Solenoid 6. Temperature Regulator 7. I/P 8. Temperature Control 9. Product OUT 10. Product IN 11. Drain Valve 12. -
Page 16: Refrigeration Piping Installation
Check with system requirements and plant capacities to ensure that refrigeration piping is sized properly. Suction Line Installation All Votator II refrigeration units operate best when provided with constant suction pressure. To ensure constant pressure do the following: •... -
Page 17: Refrigeration Valves
Waukesha Cherry-Burrell Installation Refrigeration Valves Liquid Feed Solenoid Valve Liquid Feed Solenoid Valve is for on/off control of liquid refrigerant flow. Valve is closed when de-energized. Dual Pressure Regulating Valve Dual Pressure Regulating Valve is shipped loose for installation in vapor line on discharge side of refrigeration piping. Valve regulates high-pressure for internal relief and low-pressure with on/off solenoid valve for process control. -
Page 18: Hot Gas Pressure Regulating Valve
Installation Waukesha Cherry-Burrell Hot Gas Pressure Regulating Valve Systems with hot gas include a solenoid-operated Pressure Regulating Valve for introducing and maintaining constant downstream pressure for hot gas inlet. Pumped Refrigeration Systems include a solenoid operated Hot Gas Purge Valve for each Votator hot gas discharge line. Pressure Relief Valve DANGER: Never install a shutoff This valve is located on the accumulator and should be... -
Page 19: Suggested Media Piping For Gravity Refrigeration
18. Hot Gas Pressure Regulating Valve Suggested Media Piping Liquid refrigerant from the receiver is stored in a surge drum located above the Votator II. The level in the surge drum is for Gravity Refrigeration automatically controlled by the level system provided with the equipment. - Page 20 Installation Waukesha Cherry-Burrell Level Master Control Level Switch Control HE100-060a Figure 12- Suggested Media Piping, Gravity Refrigeration - VERTICAL Table 4: Call Outs for Figure 11 (page 17) and Figure 12 1. Safety Relief Valve (Dual) 12. Liquid Refrigerant from Low Pressure Receiver 2.
-
Page 21: Electrical Equipment
If a Votator PLC Control Panel was purchased for the Votator II unit, Item 3 below is furnished loose for inclusion in Buyer’s high voltage panel and Items 7 and 8 are not needed. The PLC panel for Votator II refrigeration units duplicates the control operation shown on the following pages;... -
Page 22: Refrigeration Wiring Schematics
Installation Waukesha Cherry-Burrell Refrigeration Wiring Freeze Protection Components Schematics HE100-100 Figure 13- Suggested Electrical Schematic - Freeze Protection Components Page 20 95-03057 11/2012... -
Page 23: Gravity Refrigeration With Level Master Control (Lmc)
Waukesha Cherry-Burrell Installation Gravity Refrigeration with Level Master Control (LMC) HE100-101a Figure 14- Suggested Electrical Schematic - Gravity Refrigeration with Level Master Control (LMC) 11/2012 95-03057 Page 21... -
Page 24: Gravity Refrigeration With Level Switch
Installation Waukesha Cherry-Burrell Gravity Refrigeration with Level Switch HE100-108 Figure 15- Suggested Electrical Schematic - Gravity Refrigeration with Level Switch Page 22 95-03057 11/2012... -
Page 25: Liquid Overfeed Refrigeration System
Waukesha Cherry-Burrell Installation Liquid Overfeed Refrigeration System HE100-102 Figure 16- Suggested Electrical Schematic - Liquid Overfeed Refrigeration System 11/2012 95-03057 Page 23... -
Page 26: Media System Check
Before starting a new unit, the system should be checked for media leaks at the Votator II cylinder, the media connections, and the piping to the cylinder using the following procedures: On units jacketed for steam or liquids, follow steps 1 through 6, and then drain condensate from cylinder. -
Page 27: Mounting Scrape Cylinders - Vertical Votator Ii
Maintain minimum distance between protective cap and floor. See “Clearances” on page 9. Hydraulic System - Vertical The Vertical Votator II is furnished with a hydraulic cylinder, pump, motor, and fluid reservoir for removing and installing the Votator II mutator shaft and heat transfer tube. -
Page 28: Check Balance And Pressure Settings
4. Check hydraulic pump pressure by moving hydraulic lift foot away from Votator II unit and running cylinder in the full up, dead head position. At this point, it should be adjusted for a gauge reading of 300 to 400 psig at the pump. -
Page 29: Gravity Refrigeration System - Vertical Votator Ii
Vertical Refrigeration System located in the addendum section and Votator II Vertical Refrigeration System drawing on page 18 showing the Process Flow Diagram of the Vertical Refrigeration System. It is necessary for on-site installation of these components to insure that the refrigeration system will mate properly with the Votator II cylinders. -
Page 30: Typical Dimensional Data And Hydraulic Lift System
Installation Waukesha Cherry-Burrell Typical Dimensional Data and Hydraulic Lift System Votator II General Assembly Page 28 95-03057 11/2012... -
Page 31: Horizontal Refrigeration Assembly
Waukesha Cherry-Burrell Installation Horizontal Refrigeration Assembly 11/2012 95-03057 Page 29... -
Page 32: Vertical Refrigeration System
Installation Waukesha Cherry-Burrell Vertical Refrigeration System Page 30 95-03057 11/2012... -
Page 33: Horizontal Frame Options
Waukesha Cherry-Burrell Installation Horizontal Frame Options 11/2012 95-03057 Page 31... -
Page 34: Vertical Mounting Pole/Hydraulics
Installation Waukesha Cherry-Burrell Vertical Mounting Pole/Hydraulics SIDE FRONT VIEW VIEW Page 32 95-03057 11/2012... -
Page 35: Vertical Hydraulic Schematic
Waukesha Cherry-Burrell Installation Vertical Hydraulic Schematic 11/2012 95-03057 Page 33... -
Page 36: Operation
DO NOT expose to acid Use sanitizing solution compatible with the materials of the or acid cleaners. Votator II. If a chlorine solution is used, it must not exceed 50 ppm at 75°F (24°C) and surface contact must be limited to 10 minutes. -
Page 37: Startup Procedure
1. Start product pump using product or compatible liquid, such STARTUP SUMMARY as water. LIQUID/STEAM 2. After product flow is established, start Votator II mutator shaft Establish seal flush flow (if required). motor. Do not run Votator II without product flow. Check media availability. -
Page 38: Shutdown Procedure
Operation Waukesha Cherry-Burrell Shutdown Procedure CAUTION: The steam or These instructions are general and should be used only as a refrigeration supply valves must guide. It may be necessary to modify them to conform to actual be shut off BEFORE stopping in-plant requirements. -
Page 39: Maintenance
• Rubber or plastic mallet • Large adjustable wrench (2-3/8 inch) or WCB model 79-2 Votator II Sanitary Wrench for removing the shaft locknut • Two adjustable or open-end wrenches (15/16 inch) for removing the bearing clamp on the non-driven head •... -
Page 40: Routine Maintenance Checklist - Horizontal Votator Ii
20. Grease bearing. (Not required for Extra Heavy Duty Votator II.) Routine Maintenance 1. Tools required: Checklist - Horizontal • Rubber or plastic mallet •... - Page 41 Waukesha Cherry-Burrell Maintenance CAUTION: Failing to use the 8. Insert the Head Removal Tool (HRT) through the bearing and Head Removal tool can result in into the threaded end of the shaft, then slide the head over damage to the seal face. Use of the tool so that the seal face is past the end of the shaft.
-
Page 42: Scheduled Maintenance
Mutator Shaft Lubricate each fitting with a handgun, approximately three shots. Bearing Use a suitable NLGI Grade-2 bearing grease. (Not required for Extra Heavy Duty Votator II.) Shaft Remove shaft assembly at least once a week. Always use the removal Assembly trough skid to avoid bottom blades scoring the heat transfer tube. -
Page 43: Preventive Maintenance
Extra Heavy Duty Votator II Shaft Bearing The shaft bearing on the Extra Heavy Duty Votator II located in the opposite drive end head is a sealed bearing and does not require lubrication. -
Page 44: Shafts
The shaft trough skid should always be used when removing or installing the mutator shaft in the Horizontal Votator II (or the Vertical unit if in a horizontal position) to prevent the blade mounting pins from scoring and damaging the tube wall. -
Page 45: Care Of Heat Exchanger Tube
You may not be aware that these units are considered pressure vessels under the ASME Code, and that SPX is the only facility authorized to make OEM repairs to the removable tubes that maintain their ASME Code certification. This certification is your assurance that the equipment meets its original design pressure rating. -
Page 46: Product Side
It is also a requirement of most business insurance carriers, so you are helping to protect your company against potential fines and uninsured losses. With stakes this high, tube repair by SPX is the smart bet. Product Side The heat exchanger tube is designed to last a long time with little maintenance. -
Page 47: Jacket Side
Waukesha Cherry-Burrell Maintenance Jacket Side For Units Using Steam, Water, Or Liquid The jacket side of the heat transfer tube has a sealed cover that allows the media flow to circulate around the tube. If it becomes coated with foreign matter and heat transfer is reduced, it can be cleaned by pumping a detergent solution compatible with the carbon steel jacket at a rate of about 100 gpm. -
Page 48: Scraper Blade Removal & Replacement
Maintenance Waukesha Cherry-Burrell Scraper Blade Removal & Replacement 1. Remove scraper blades by lifting up and pulling them from the pins. PEEK Blades have a locking groove. 2. After lifting, push to the right before pulling them from the pins. NOTE: Blades should be kept in the same position on mutator shaft throughout life of blade. -
Page 49: Maintenance Of Horizontal Votator Ii
Maintenance Maintenance of Horizontal DANGER: Before doing any maintenance work on the Votator II, lock out and tag out equipment. Votator II Shaft Removal - Horizontal Unit 1. Check to make sure all supply lines to unit are closed, locked out and tagged out. -
Page 50: Shaft Installation - Horizontal Unit
Maintenance Waukesha Cherry-Burrell 11. Remove scraper blades and service as necessary. See “Scraper Blade Maintenance” on page 45 NOTE: Blades should be kept in the same position on the mutator shaft throughout the life of blade. Make sure blades are removed and reinstalled in the same location on the shaft. - Page 51 Waukesha Cherry-Burrell Maintenance 10. Make sure O-ring (See Figure 35, Item A) is installed in the opposite drive end head. Lubricate lightly Figure 35 - Opposite Drive End Head O-ring 11. Install opposite drive end head by reversing procedure for removal of head.
-
Page 52: Heat Exchanger Tube Removal - Horizontal Unit
1. Check to insure all supply lines to unit are closed and locked maintenance work on the and tagged out. Votator II, lock out and tag out equipment. 2. Make sure that entire unit is purged of fluids (product, coolant, refrigerant, etc.) 3. -
Page 53: Heat Exchanger Tube Installation - Horizontal Unit
12. Install opposite drive end head. Figure 41- Install Tube to Jacket Bolts Maintenance of Vertical DANGER: Before doing any maintenance work on the Votator II, lock out and tag out equipment. Votator II Shaft Removal - Vertical Unit 1. Purge all product from unit. -
Page 54: Shaft Installation - Vertical Unit
Maintenance Waukesha Cherry-Burrell 6. Unlatch locking latch. 7. The head has an ON-OFF engraving on the rim, located just above product outlet. Rotate head in OFF direction until head disengages. 8. Lower head until hydraulic rod is fully extended. See Figure 9. -
Page 55: Heat Exchanger Tube Removal -Vertical Unit
Waukesha Cherry-Burrell Maintenance 7. If optional blade aligning tool is used, install it on the bayonet ring of heat transfer tube. Place each half of the ring on the bayonet and rotate it as one piece. 8. Raise shaft slowly, tucking blades into shaft while shaft and blade assembly is being inserted into tube. - Page 56 Maintenance Waukesha Cherry-Burrell 5. Remove the three (3) bolts holding front jacket cover in place. 6. Remove the non-driven product head from mutator shaft. Figure 49 - Remove Front Jacket Cover Bolts 7. Reattach head to tube. See Figure 50. Reattach shaft nut cover and clamp, and use lift to position non-driven end head.
- Page 57 Waukesha Cherry-Burrell Maintenance 12. Lower head and tube assembly and service as required. 13. Lubricate and install new O-rings on both ends of tube. 14. Install new packing ring (on steam or liquid tubes). 15. To reinstall tube, reverse the procedure. 16.
-
Page 58: Mechanical Seal Maintenance
Maintenance Waukesha Cherry-Burrell Mechanical Seal The mechanical seals on the Votator II are the same on both the non-driven and driven ends of the unit. The O-rings and seal Maintenance materials have been selected for the product specifications. Various options are shown in the Parts Lists starting on page 63. -
Page 59: Single Mechanical Seal Installation
Waukesha Cherry-Burrell Maintenance Single Mechanical Seal Installation After the head insert and the body insert are installed, the remaining components are installed as follows: 1. Place wavy washer spring (See Figure 56, Item A) on shaft. 2. Install seal back-up ring. (See Figure 56, Item B). 3. -
Page 60: 2012 Primary/Secondary Seal Head Insert Removal And Installation
Maintenance Waukesha Cherry-Burrell To install a new primary or secondary insert, lubricate o-rings and the inside bore. Insert in the head with an even distribution of force on face. Protect the face with plastic to avoid damage. 2012 Primary/Secondary Seal Head Insert Removal and Installation The primary seal head insert from 2012 onward has two parts, a gland and a seat, but is removed by pushing with the special Seal... -
Page 61: One-Piece Primary Seal Body (Rotating Seal Face)
Waukesha Cherry-Burrell Maintenance One-Piece Primary Seal Body (Rotating Seal Face) See Figure 63. Removable Seal Body Insert (Rotating Seal Face) The rotating seal face is referred to as the Seal Body Insert. This part is designed to wear at a greater frequency than the seal head insert. -
Page 62: Assembly Of Secondary Seal Body (For Double Mechanical Seal Only)
Maintenance Waukesha Cherry-Burrell Assembly of Secondary Seal Body (For Double Mechanical Seal Only) The secondary seal body has one O-ring that holds the insert stationary in the body. To install the insert in the seal body: 1. Place O-ring in body (no lubrication). 2. -
Page 63: Servicing Mechanical Seals - Vertical Votator Ii
Figure 70 - Double Mechanical Seal Installed Servicing Mechanical Seals - Vertical Votator II The top mechanical seal can be serviced by lowering the shaft to the floor and removing the seals from the shaft while the spline end is in the heat transfer tube. - Page 64 Maintenance Waukesha Cherry-Burrell 8. Remove clamp on head. (See Figure 74, Item A) and shaft nut guard. 9. While supporting head, remove shaft nut. (Nut is left hand threaded.) Figure 74 - Remove Head Clamp 10. Grasp head with both hands, remove it from shaft. 11.
-
Page 65: Parts Lists
Waukesha Cherry-Burrell Parts Lists Parts Lists Latch ITEM # PART DESCRIPTION PART # VII Locking Latch LL923221 Washer Plain 3/8” 18-8 Narrow 43-30 Wing Nut LL2200281 Acorn Nut LL711155 Spacer LL2200321 Stud LL2200277 Hexagon Head Shoulder Screw LL925499 Spacer Washer LL931315 Product Heads APPLICATION... -
Page 66: Cylinder Assembly
Parts Lists Waukesha Cherry-Burrell Cylinder Assembly HE100-039b 16,36 Spider Head Option Extra Heavy Duty Bearing Option- obsolete after 2009 HE100-124 Extra Heavy Duty Bearing Option (Current Design) Page 64 95-03057 11/2012... - Page 67 Heavy Hex Head Bolt ASME SA193-B8, Class 1 LL928781 3/8-16 x 1 Bearing Retainer Votator II LL923214 Extra Heavy Duty Votator II (obsolete after 2009) LL118393 Extra Heavy Duty Votator II (Current design) 128476+ Clamp Ring Spider Head Only LL117678...
-
Page 68: Cylinder Assembly - Shaft
Parts Lists Waukesha Cherry-Burrell Cylinder Assembly - Shaft SHAFT SHAFT SIZE SEAL TYPE PART # SEAL TYPE PART # MODEL MODEL 6 x 24 Single Mechanical 5-1/4" dia LL118919 Double Mechanical 4" dia LL122760 4-1/2" dia LL936881 6 x 36 Single Mechanical 2-1/2"... -
Page 69: Cylinder Assembly - Removable Tube
Waukesha Cherry-Burrell Parts Lists Cylinder Assembly - Removable Tube SIZE APPLICATION CODE TYPE DESCRIPTION PART # 316 SS TW/WO RINGS LL936879 6 x 24 316 SS CR 130906+ NI/CR LL122763 VAPOR 316 SS TW/W RINGS LL118829 NI/CR LL118909 6 x 36 NI/CR LL930693 316 SS TW/WO RINGS... - Page 70 Parts Lists Waukesha Cherry-Burrell 2012 Double Mechanical Seal HE100-113 HE100-116 HE100-115 Seal Installation/Removal Tool ODE Head Installation/Removal Tool LL121191 130007+ Page 68 95-03057 11/2012...
-
Page 71: 2012 Single And Double Mechanical Seal
Waukesha Cherry-Burrell Parts Lists 2012 Single and Double Mechanical Seal QTY PER ITEM # DESCRIPTION MATERIAL OPTION PART # SEAL Spring-VII Product Seal (Wavy Washer) Standard LL922313A O-ring Buna N75237 EPDM E70237 V70237-680 Seal ring Chrome oxide LL934871 Seal Body-VII Secondary LL932357 O-ring Buna... - Page 72 Parts Lists Waukesha Cherry-Burrell Double Mechanical Seal HE100-114 HE100-116 ODE Head Installation/Removal Tool LL121191 Page 70 95-03057 11/2012...
-
Page 73: One Piece Single & Double Mechanical Seal
Waukesha Cherry-Burrell Parts Lists One Piece Single & Double Mechanical Seal QTY PER ITEM # DESCRIPTION MATERIAL OPTION PART # SEAL Wavy Washer (Primary) Standard LL922313 Seal Body O-ring (Primary) Buna N75237 Fluoroelastomer V70237-680 EPDM E70237 Seal Ring (Secondary), if required LL934871 Seal Body (Secondary), if required LL932357... - Page 74 Parts Lists Waukesha Cherry-Burrell Single Mechanical Seal Page 72 95-03057 11/2012...
-
Page 75: Single Mechanical Seal
Waukesha Cherry-Burrell Parts Lists Single Mechanical Seal ITEM # DESCRIPTION QTY PER SEAL MATERIAL OPTION PART # Wavy Washer Standard LL922313 Particulate Option LL19625A Seal Body U-cup Buna LL700014A05 Fluoroelastomer LL700014A08 EPDM LL700014A03 Seal Keeper O-ring Buna N75226 Fluoroelastomer V70226-680 EPDM E70226 Flushing Lip Seal... -
Page 76: Vertical Refrigeration Piping
Parts Lists Waukesha Cherry-Burrell Vertical Refrigeration Piping Page 74 95-03057 11/2012... - Page 77 Waukesha Cherry-Burrell Parts Lists Vertical Refrigeration Piping ITEM # DESCRIPTION QTY PER ACC NOTES PART # Accumulator 16" Diameter LL929516 Refrigeration Piping Upper Accumulator Piping LL930348 Refrigeration Piping Lower Accumulator Piping LL930349 Weld Cap One Cylinder Only LL901386 Weld Cap One Cylinder Only LL901387 Refrigeration Piping...
-
Page 78: Vertical Frame/Hydraulics
Parts Lists Waukesha Cherry-Burrell Vertical Frame/Hydraulics ITEM # DESCRIPTION QTY PER POLE MODEL PART # Hydraulic Valve LL928736 Push - Pull Handle LL929343 Hydraulic Power Assembly 3/4 HP CLR LL928737 Pump/Adapter Kit Only LL928737-1 Shaft Stop Clamp 4” Shaft LL935529 4-1/2”... -
Page 79: Shaft Heater (Optional)
Waukesha Cherry-Burrell Parts Lists Shaft Heater (Optional) ITEM # DESCRIPTION MODEL PART # Shaft Nut Guard LL929346 Shaft Locknut LL119275A Gasket LL117720 O-ring N70222-674 Shaft Heater Pipe 6 x 24 Cylinder LL123001 6 x 36 Cylinder 6 x 48 Cylinder LL112278E 6 x 72 Cylinder 6 x 84 Cylinder... -
Page 80: Votator Ii Blades
Parts Lists Waukesha Cherry-Burrell Votator II Blades QUANTITY MATERIAL REMARKS PART NO. 6x84 6x72 6x48 6x36 6x24 410SS LL900127 CELCON LL900129 BRASS LL916284 17-7 SS LL900124 PEEK LL118683 410SS LL125801 Open Style BRASS LL918089 17-7 SS LL919100 CELCON Open Style... -
Page 81: Troubleshooting
Waukesha Cherry-Burrell Troubleshooting Troubleshooting PROBLEM POSSIBLE CAUSE SUGGESTED ACTION Freeze-up. Power failure. Check power supply. Product outlet temperature Adjust process to raise product outlet too low. temperature. Product flow rate too low. Adjust process to increase product flow. Check that pump is matched to process. - Page 82 Troubleshooting Waukesha Cherry-Burrell PROBLEM POSSIBLE CAUSE SUGGESTED ACTION Increased gas discharge Air in refrigeration system. Refer to “Water and Air in temperature. Refrigeration System” on page 82. Seal head will not install Twisted when installed. Lubricate before installing. properly. Installed wrong size, distorted Replace O-ring.
- Page 83 Waukesha Cherry-Burrell Troubleshooting PROBLEM POSSIBLE CAUSE SUGGESTED ACTION Product leaking: Seal insert cocked when Remove and reinstall, making sure installed. the o-ring is not twisted. • Between lapped or polished Seal body and/or seal faces Replace entire seal. surfaces of seal head insert worn or damaged.
-
Page 84: Unthawing A Frozen System
Troubleshooting Waukesha Cherry-Burrell Unthawing A Frozen To unthaw a system that has frozen-up, perform the following procedures. The cause of freeze-up MUST BE corrected before System operation is restarted. See the Troubleshooting Chart starting on page 79 for cause and solution aids. 1. - Page 86 P: (262) 728-1900 or (800) 252-5200 F: (262) 728-4904 or (800) 252-5012 E: wcb@spx.com SPX reserves the right to incorporate our latest design and material changes without notice or obligation. Design features, materials of construction and dimensional data, as described in this bulletin, are provided for your information only and should not be relied upon unless confirmed in writing.
