SAMWONTECH
22.5.2 Sub channel heater disconnection signal setting screen
▶ It is a screen to set the sub channel heater disconnection signal.
①
[Fig. 22-10] Sub channel heater disconnection signal setting screen
.
① It sets the Sub channel heater disconnection signal
Table 22-5 Sub channel heater disconnection signal setting screen parameter
Parameter
Setting range
Unit
Initial data
SCH#n HBA relay
0~32
ABS
0
* #n = It can be set in 1 ~ 6.
2nd Edition of TEMP2000M_Series IM : April. 8. 2014
Page 165 / 176
