SAMWONTECH
20.3 BMP file making
▶ Use [Photoshop program]을 for making BMP file certainly.
☞ "[Picture Plat]" used generally in the computer cannot be used because the bit map cannot be set in
16BIT.
▶ BMP file composition
☞ 16BIT(X1 R5 G5 B5) BMP
▶ Resolution
☞ User screen : 640 X 480 Pixel
☞ Initial screen : 640 X 480 Pixel
☞ DI error screen : 520 X 422 Pixel
▶ File name
☞ User screen: CS1.BMP, CS2.BMP, CS3.BMP ~ CS14.BMP, CS15.BMP, CS16.BMP (Total 16 units)
☞ Initial screen : INIT.BMP
☞ DI error screen : DI1.BMP, DI2.BMP, DI3.BMP ~ DI14.BMP, DI15.BMP, DI16.BMP (Total 16 units)
－ It cannot be used when the user screen, initial screen and DI error screen are saved with another file
name which is not designated.
－ Use the extension with ".BMP" when the file is saved in [Photoshop program].
☞ The folder name inside the SD CARD is appointed with 'BMP.'
※ With regards to the BMP instruction manual, download from the homepage of our company.
2nd Edition of TEMP2000M_Series IM : April. 8. 2014 Page 150 / 176
