19.2 DI error name

19.2.1 DI error name setting
▶ It can be only set when display type is "Character".
▶ This is the screen for inputting DI error name.
▶ Di error name can be input up to 24 characters.
[Fig. 19-7] Display name setting screen in case of DI occurrence
Table 19-6. DI error name setting screen parameter
Parameter
DI #n name
DI #m name
* #n = 1 ~ 8
* #m = 9 ~ 16
2nd Edition of TEMP2000M_Series IM : April. 8. 2014
[Fig. 19-6] DI error name setting screen
Setting range
0 ~ 9, A ~ Z, Special character (up
to 24 characters)
0 ~ 9, A ~ Z, Special character (up
to 42 characters)
Unit Initial data
ABS THE DI#n ERROR OCCURRED
ABS THE DI#m ERROR OCCURRED
Page 142 / 176
